– 24 –
D756 8-719-051-01 LED CL-170HR-CD-T (BL SKIP)
< IC >
IC301 8-759-440-52 IC TA2103F
IC601 8-759-356-46 IC MM1279XVBE
IC701 8-759-479-05 IC MSM6576-90GS-K
IC702 8-759-280-85 IC PST9010NL
IC703 8-759-430-08 IC PST9008NL
IC704 8-759-469-63 IC S-81215SGUP-DQK-T1
< JACK >
J701 1-779-867-41 JACK (2 REMOTE)
< PHOTO INTERRUPTER >
PH701 8-719-988-15 PHTO REFLECTOR PR-11-C
< TRANSISTOR >
Q301 8-729-230-72 TRANSISTOR 2SA1362YG
Q302 8-729-420-50 TRANSISTOR UN5215
Q303 8-729-420-50 TRANSISTOR UN5215
Q304 8-729-422-39 TRANSISTOR XN4404
Q305 8-729-420-50 TRANSISTOR UN5215
Q501 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q502 8-729-115-28 TRANSISTOR BN1L3Z-K
Q503 8-729-403-17 TRANSISTOR XN1215
Q504 8-729-030-54 TRANSISTOR MSB1218A-RT1
Q601 8-729-402-84 TRANSISTOR XN4601
Q701 8-729-422-51 TRANSISTOR UN5110-QRS
Q702 8-729-421-29 TRANSISTOR UN5216R
Q703 8-729-230-72 TRANSISTOR 2SA1362YG
Q704 8-729-030-54 TRANSISTOR MSB1218A-RT1
Q705 8-729-421-29 TRANSISTOR UN5216R
Q706 8-729-230-72 TRANSISTOR 2SA1362YG
Q721 8-729-422-18 TRANSISTOR XN4315
Q722 8-729-030-53 TRANSISTOR MSD1819A-RT1
Q751 8-729-421-77 TRANSISTOR UN5210-R-TX
Q752 8-729-022-66 TRANSISTOR XN1210-TX
Q753 8-729-022-66 TRANSISTOR XN1210-TX
< RESISTOR >
R101 1-216-812-11 METAL CHIP 180 5% 1/16W
R103 1-216-847-11 METAL CHIP 150K 5% 1/16W
R104 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
R110 1-216-809-11 METAL CHIP 100 5% 1/16W
R111 1-216-844-11 METAL CHIP 82K 5% 1/16W
R112 1-216-793-11 METAL GLAZE 4.7 5% 1/16W
R113 1-216-805-11 METAL CHIP 47 5% 1/16W
(FR)
R113 1-216-864-11 METAL CHIP 0 (EXCEPT FR)
R201 1-216-812-11 METAL CHIP 180 5% 1/16W
R203 1-216-847-11 METAL CHIP 150K 5% 1/16W
R204 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R209 1-216-821-11 METAL CHIP 1K 5% 1/16W
R210 1-216-809-11 METAL CHIP 100 5% 1/16W
R211 1-216-844-11 METAL CHIP 82K 5% 1/16W
R212 1-216-793-11 METAL GLAZE 4.7 5% 1/16W
R213 1-216-805-11 METAL CHIP 47 5% 1/16W
(FR)
R213 1-216-864-11 METAL CHIP 0 (EXCEPT FR)
R301 1-218-891-11 METAL GLAZE 68K 0.50% 1/16W
R302 1-216-837-11 METAL CHIP 22K 5% 1/16W
R303 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R304 1-218-295-11 METAL GLAZE 43K 5% 1/16W
R305 1-216-841-11 METAL CHIP 47K 5% 1/16W
R306 1-216-793-11 METAL GLAZE 4.7 5% 1/16W
R307 1-216-849-11 METAL CHIP 220K 5% 1/16W
R308 1-216-837-11 METAL CHIP 22K 5% 1/16W
R309 1-216-821-11 METAL CHIP 1K 5% 1/16W
R502 1-216-833-11 METAL CHIP 10K 5% 1/16W
R601 1-216-849-11 METAL CHIP 220K 5% 1/16W
R602 1-216-817-11 METAL CHIP 470 5% 1/16W
R603 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R604 1-216-837-11 METAL CHIP 22K 5% 1/16W
R605 1-216-809-11 METAL CHIP 100 5% 1/16W
R606 1-216-849-11 METAL CHIP 220K 5% 1/16W
R607 1-216-849-11 METAL CHIP 220K 5% 1/16W
R608 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R609 1-216-809-11 METAL CHIP 100 5% 1/16W
R701 1-216-813-11 METAL CHIP 220 5% 1/16W
R702 1-216-857-11 METAL CHIP 1M 5% 1/16W
R703 1-216-849-11 METAL CHIP 220K 5% 1/16W
R706 1-216-845-11 METAL CHIP 100K 5% 1/16W
R708 1-216-821-11 METAL CHIP 1K 5% 1/16W
R709 1-216-001-00 METAL CHIP 10 5% 1/10W
R710 1-216-001-00 METAL CHIP 10 5% 1/10W
R711 1-216-001-00 METAL CHIP 10 5% 1/10W
R712 1-216-821-11 METAL CHIP 1K 5% 1/16W
R721 1-216-815-11 METAL CHIP 330 5% 1/16W
R722 1-216-847-11 METAL CHIP 150K 5% 1/16W
R723 1-216-849-11 METAL CHIP 220K 5% 1/16W
R731 1-218-870-11 METAL GLAZE 9.1K 0.50% 1/16W
R732 1-218-836-11 METAL GLAZE 360 0.50% 1/16W
R751 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R752 1-216-837-11 METAL CHIP 22K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB301 1-233-872-21 RES, NETWORK (CHIP TYPE) 33K
RB302 1-234-085-11 RES, NETWORK
RB303 1-234-086-11 RES, NETWORK
RB701 1-233-873-21 RES, NETWORK
RB731 1-233-941-21 RES, NETWORK
RB751 1-233-414-11 RES, CHIP NETWORK 4.7K
< VARIABLE RESISTOR >
RV301 1-225-502-11 RES, VAR, CARBON 10K/10K (VOLUME)
RV601 1-223-576-11 RES, ADJ, METAL GLAZE 2.2K (TAPE SPEED)
< SWITCH >
S701 1-762-498-21 SWITCH, PUSH (1 KEY) (HOLDER)
S702 1-572-581-11 SWITCH, SLIDE (FWD/STOP/REV)
S703 1-762-078-11 SWITCH, SLIDE ($ HOLD)
S704 1-771-053-21 SWITCH, KEY BOARD (p)
S705 1-771-053-21 SWITCH, KEY BOARD (œREPEAT)
S706 1-771-053-21 SWITCH, KEY BOARD (FF AMS)
AUDIO
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
