SECTION 1
GENERAL
LOCATION AND FUNCTION OF CONTROLS
Tape player section and general
r
Main unit
r
Headphones with Remote Control
This section is extracted from
instruction manual.
1 OPEN knob
2 Contact for dry battery case
3 Tape operation buttons
4 Rechargeable battery case
5 BL SKIP indicatior
6 AVLS indicatior
7 FUNCTION button
8 HOLD switch
9 MB/GRV (Mega Bass/Groove) indicator
0 Main unit : VOLUME knob
Remote control : VOL knob
!¡ BATT indicator
!™ 2 REMOTE jack
!£ a (DOLBY) NR indicator
!¢ SOUND/AVLS (Auto Volume limitter
system) switch
!∞ Micro plug
WM-EX655
!∞
3
3
8
!º
!¢
8
!º
Left Right
Left Righ
