– 23 –
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : m , for example :
uA.... : m A.... , uPA.... : m PA....
uPB.... : m PB.... , uPC.... : m PC....
uPD.... : m PD....
• CAPACITORS
uF : m F
• COILS
uH : m H
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-3061-556-A AUDIO BOARD, COMPLETE (EX655)
A-3061-693-A AUDIO BOARD, COMPLETE (EX668 : FR)
A-3021-130-A AUDIO BOARD, COMPLETE
(EX668 : EXCEPT FR)
**********************
< CAPACITOR >
C101 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C104 1-115-156-11 CERAMIC CHIP 1uF 10V
C105 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C106 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C107 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C108 1-115-156-11 CERAMIC CHIP 1uF 10V
C109 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C110 1-135-180-21 TANTALUM CHIP 3.3uF 20% 6.3V
C111 1-115-156-11 CERAMIC CHIP 1uF 10V
C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C201 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C204 1-115-156-11 CERAMIC CHIP 1uF 10V
C205 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C206 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C207 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C208 1-115-156-11 CERAMIC CHIP 1uF 10V
C209 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C210 1-135-180-21 TANTALUM CHIP 3.3uF 20% 6.3V
C211 1-115-156-11 CERAMIC CHIP 1uF 10V
C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C301 1-128-015-11 SOLID CHIP 22uF 20% 4V
C302 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C303 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C304 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C305 1-135-316-11 TANTAL. CHIP 22uF 20% 2.5V
C306 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C307 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C308 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C310 1-117-578-11 TANTAL. CHIP 470uF 20% 2.5V
C311 1-115-156-11 CERAMIC CHIP 1uF 10V
C312 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C313 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C314 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C315 1-115-156-11 CERAMIC CHIP 1uF 10V
C316 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C318 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C319 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C501 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C502 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C601 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C603 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C604 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C605 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C608 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C701 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C702 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C703 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C704 1-115-156-11 CERAMIC CHIP 1uF 10V
C705 1-115-156-11 CERAMIC CHIP 1uF 10V
C706 1-115-156-11 CERAMIC CHIP 1uF 10V
C707 1-115-156-11 CERAMIC CHIP 1uF 10V
C708 1-115-156-11 CERAMIC CHIP 1uF 10V
C721 1-164-156-11 CERAMIC CHIP 0.1uF 25V
CB301 1-117-968-11 CERAMIC CHIP (ARRAY) 680P
CB302 1-125-786-11 CERAMIC CHIP (ARRAY)
CB303 1-125-785-11 CERAMIC CHIP (ARRAY)
< CONNECTOR >
CN301 1-766-336-21 CONNECTOR, FFC/FPC 6P
< DIODE >
D101 8-719-423-35 DIODE MA8120-H
D201 8-719-423-35 DIODE MA8120-H
D501 8-719-049-09 DIODE 1SS367-T3SONY
D701 8-719-404-49 DIODE MA111
D702 8-719-423-35 DIODE MA8120-H
D703 8-719-423-35 DIODE MA8120-H
D704 8-719-049-09 DIODE 1SS367-T3SONY
D705 8-719-423-35 DIODE MA8120-H (EX668)
D751 8-719-051-01 LED CL-170HR-CD-T (BATT)
D752 8-719-051-01 LED CL-170HR-CD-T (MB)
D753 8-719-051-01 LED CL-170HR-CD-T (GRV)
D754 8-719-051-01 LED CL-170HR-CD-T (a NR)
D755 8-719-051-01 LED CL-170HR-CD-T (AVLS)
AUDIO
• Abbreviation
FR : French
JEW : Tourist
When indicating parts by reference num-
ber, please include the board.
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
Ver 1.1 1998.10
