Sony WM-FX171

— 28 —
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
6-3. MECHANISM SECTION-1 (MF-WMFX171-114)
101 3-013-560-11 BELT
102 3-703-816-31 SCREW (M1.4), SPECIAL HEAD
103 3-921-042-01 GEAR (REEL)
104 3-703-816-73 SCREW (M1.4), SPECIAL HEAD
105 X-3369-749-1 PINCH LEVER (N) ASSY
106 3-920-996-01 SPRING (PINCH N)
HP901 1-667-291-11 HEAD FLEXIBLE BOARD(W/PLAYBACK HEAD)
M901 1-763-073-11 MOTOR
104
103
105
106
102
101
M901
HP901
