Sony WM-FX171

NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 7
ELECTRICAL PARTS LIST
MAIN
A-3021-209-A MAIN BOARD, COMPLETE (FX171: US)
*********************
A-3021-044-A MAIN BOARD, COMPLETE (FX173: FR)
*********************
A-3021-048-A MAIN BOARD, COMPLETE (FX173: EE)
*********************
A-3021-049-A MAIN BOARD, COMPLETE (FX173: E, CH)
*********************
A-3021-045-A MAIN BOARD, COMPLETE (FX173: EA)
*********************
A-3021-046-A MAIN BOARD, COMPLETE (FX173: C&SA)
*********************
A-3021-007-A MAIN BOARD, COMPLETE (FX171: AEP)
*********************
A-3021-032-A MAIN BOARD, COMPLETE (FX171: IT)
*********************
A-3021-038-A MAIN BOARD, COMPLETE (FX171: FR)
*********************
A-3021-034-A MAIN BOARD, COMPLETE (FX171: EE)
*********************
A-3021-035-A MAIN BOARD, COMPLETE (FX171: E, CH)
*********************
A-3021-036-A MAIN BOARD, COMPLETE (FX171: EA)
*********************
A-3021-037-A MAIN BOARD, COMPLETE (FX171: C&SA, PA)
*********************
A-3021-135-A MAIN BOARD, COMPLETE (FX171: JE)
*********************
A-3021-050-A MAIN BOARD, COMPLETE (FX173: CND)
*********************
A-3021-051-A MAIN BOARD, COMPLETE (FX173: AEP)
*********************
A-3021-047-A MAIN BOARD, COMPLETE (FX173: IT)
*********************
A-3021-033-A MAIN BOARD, COMPLETE (FX177)
*********************
3-019-862-01 TERMINAL (+), BATTERY
3-022-293-01 KNOB, TUNING
3-022-294-01 POINTER
3-022-579-01 TERMINAL (–), BATTERY
< CAPACITOR >
C1 1-163-083-00 CERAMIC CHIP 1PF 50V
(EXCEPT IT, EA)
C1 1-163-086-00 CERAMIC CHIP 3PF 50V
(IT, EA)
C2 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
(US, AEP, FR, E, C&SA, PA, CH, CND)
C2 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
(IT, EA)
C2 1-163-087-00 CERAMIC CHIP 4PF 50V
(EE, JE)
MAIN
• Abbreviation
CND : Canadian
IT : Italian
EE : East European
EA : Saudi Arabia
FR : French
PA : Panama
C & SA : Central and South America
CH : Chinese
JE : Tourist
— 13 — — 14 —
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C3 1-163-100-00 CERAMIC CHIP 20PF 5% 50V
(US, AEP, FR, E, C&SA, PA, CH, CND)
C3 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
(FX171: IT, EA)
C3 1-163-089-00 CERAMIC CHIP 6PF 50V
(EE, JE)
C3 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
(FX173: IT, EA)
C4 1-163-089-00 CERAMIC CHIP 6PF 50V
(US, C&SA, PA, CND)
C4 1-163-091-00 CERAMIC CHIP 8PF 50V
(AEP, FR, EE, E, CH, JE)
C4 1-164-275-91 CERAMIC CHIP 9PF 5% 50V
(IT, EA)
C5 1-162-937-11 CERAMIC CHIP 6PF 0.5PF 50V
C6 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C7 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C8 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C9 1-115-156-11 CERAMIC CHIP 1uF 10V
C10 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C11 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C12 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C14 1-124-259-11 ELECT 4.7uF 20% 16V
C15 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C16 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C17 1-126-154-11 ELECT 47uF 20% 6.3V
C18 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(US, C&SA, PA, CND)
C18 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
(AEP, IT, FR, EE, E, EA, CH, JE)
C19 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(US, C&SA, PA, CND)
C19 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
(AEP, IT, FR, EE, E, EA, CH, JE)
C22 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C23 1-115-156-11 CERAMIC CHIP 1uF 10V
C24 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C26 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C28 1-163-085-00 CERAMIC CHIP 2PF 50V
(FX171: IT, EA)
C28 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
(FX173: IT, EA)
C101 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C104 1-126-157-11 ELECT 10uF 20% 16V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
C106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(FX171/FX177)
C106 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(FX173)
C107 1-115-156-11 CERAMIC CHIP 1uF 10V
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C204 1-126-157-11 ELECT 10uF 20% 16V
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(FX171/FX177)
C206 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(FX173)
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-216-864-11 METAL CHIP 0 5% 1/16W
(US, AEP, IT, FR, EE, CND)
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(E, C&SA, EA, PA, CH)
C303 1-126-153-11 ELECT 22uF 20% 6.3V
C304 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C305 1-126-176-11 ELECT 220uF 20% 10V
C306 1-115-156-11 CERAMIC CHIP 1uF 10V
C308 1-126-162-11 ELECT 3.3uF 20% 50V
C309 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(FX171/FX177)
C309 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(FX173)
C310 1-115-156-11 CERAMIC CHIP 1uF 10V
C311 1-113-619-11 CERAMIC CHIP 0.47uF 10V
(FX171/FX177)
C311 1-115-156-11 CERAMIC CHIP 1uF 10V
(FX173)
C312 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(FX171/FX177)
C312 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(FX173)
C313 1-115-156-11 CERAMIC CHIP 1uF 10V
C314 1-115-156-11 CERAMIC CHIP 1uF 10V
C315 1-126-153-11 ELECT 22uF 20% 6.3V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C318 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C319 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C322 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C325 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C328 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C329 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C601 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C602 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C603 1-126-176-11 ELECT 220uF 20% 10V
C605 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C606 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C607 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C608 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C609 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C610 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< FILTER >
CF1 1-527-870-00 FILTER 455kHz
CF2 1-767-733-71 FILTER ASSY, CERAMIC 10.7MHz
< CONNECTOR >
CN301 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P
CN302 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P (FX171/FX177)
* CN302 1-784-527-21 CONNECTOR, FPC (ZIF) 9P (FX173)
< CONPOSITION CIRCUIT BLOCK >
CP1 1-236-711-21 FILTER, BAND PASS
(US, AEP, IT, FR, E, C&SA, EA, PA, CH, CND)
CP1 1-239-813-21 FILTER, BAND PASS (EE, JE)
< VARIABLE CAPACITOR >
CT1 1-141-595-21 CAP, VAR
CV1 1-141-595-21 CAP, VAR (TUNING)
< DIODE >
D120 8-719-067-62 LED LNJ210C6AOSO (BATT)
< IC >
IC1 8-759-493-20 IC TA2111F-(EL)
IC301 8-759-285-29 IC LA4582CM
IC601 8-759-447-73 IC LB1979V-TLM
< JACK >
J301 1-750-061-11 JACK,DC(POLARITY UNIFIED TYPE) (DC IN 3V)
(E, C&SA, EA, PA, CH, JE)
J302 1-565-287-11 JACK (HEADPHONES)
< JUMPER RESISTOR >
JR1 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, IT, FR, EE, E, EA, CH, JE)
JR2 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, IT, FR, EE, E, EA, CH, JE)
JR3 1-216-821-11 METAL CHIP 1K 5% 1/16W
(AEP, IT, FR, EE, E, EA, CH, JE)
JR4 1-216-864-11 METAL CHIP 0 5% 1/16W
(US, C&SA, PA, CND)
JR5 1-216-864-11 METAL CHIP 0 5% 1/16W
(US, C&SA, PA, CND)
< COIL >
L1 1-501-962-11 ANTENNA, FERRITE-ROD (MW)
L2 1-416-623-11 COIL (WITH CORE)
(US, AEP, FR, E, C&SA, PA, CH, CND)
L2 1-416-624-11 COIL (WITH CORE) (IT, EA)
L2 1-416-625-11 COIL (WITH CORE) (EE, JE)
L3 1-416-626-11 COIL (WITH CORE) (US, AEP, FR, E, C&SA,
PA, CH, CND)
L3 1-416-627-11 COIL (WITH CORE) (IT, EA)
L3 1-416-628-11 COIL (WITH CORE) (EE, JE)
L4 1-406-408-21 COIL (OSC) (US, AEP, FR, EE, E, C&SA, PA,
CH,CND)
L4 1-406-409-11 COIL (OSC) (IT, EA, JE)
L101 1-414-760-21 INDUCTOR CHIP 0uH
L201 1-414-760-21 INDUCTOR CHIP 0uH
L301 1-414-760-21 INDUCTOR CHIP 0uH
L302 1-414-760-21 INDUCTOR CHIP 0uH
