Sony WM-FX171

— 15 —
< TRANSISTOR >
Q2 8-729-216-22 TRANSISTOR 2SA1162-G
Q101 8-729-207-65 TRANSISTOR RN1410
Q201 8-729-207-65 TRANSISTOR RN1410
Q301 8-729-230-49 TRANSISTOR 2SC2712-YG
Q302 8-729-216-22 TRANSISTOR 2SA1162-G
< RESISTOR >
R1 1-216-791-11 METAL CHIP 3.3 5% 1/16W
(US)
R1 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R2 1-216-839-11 METAL CHIP 33K 5% 1/16W
R3 1-216-835-11 METAL CHIP 15K 5% 1/16W
(EXCEPT FR)
R3 1-216-841-11 METAL CHIP 47K 5% 1/16W
(FR)
R4 1-216-835-11 METAL CHIP 15K 5% 1/16W
(EXCEPT FR)
R4 1-216-841-11 METAL CHIP 47K 5% 1/16W
(FR)
R5 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R6 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R7 1-216-815-11 METAL CHIP 330 5% 1/16W
R8 1-216-797-11 METAL CHIP 10 5% 1/16W
R9 1-216-815-11 METAL CHIP 330 5% 1/16W
R101 1-216-821-11 METAL CHIP 1K 5% 1/16W
R103 1-216-835-11 METAL CHIP 15K 5% 1/16W
R104 1-216-835-11 METAL CHIP 15K 5% 1/16W
R105 1-216-855-11 METAL CHIP 680K 5% 1/16W
R106 1-216-818-11 METAL CHIP 560 5% 1/16W
R107 1-216-789-11 METAL CHIP 2.2 5% 1/16W
(US, AEP, IT, EE, CND)
R107 1-216-796-11 RES,CHIP 8.2 5% 1/16W
(FR)
R107 1-216-797-11 METAL CHIP 10 5% 1/16W
(E, C&SA, EA, PA, CH, JE)
R109 1-216-850-11 METAL CHIP 270K 5% 1/16W
(US, AEP, IT, FR, EE, CND)
R109 1-216-846-11 METAL CHIP 120K 5% 1/16W
(E, C&SA, EA, PA, CH, JE)
R120 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R201 1-216-821-11 METAL CHIP 1K 5% 1/16W
R203 1-216-835-11 METAL CHIP 15K 5% 1/16W
R204 1-216-835-11 METAL CHIP 15K 5% 1/16W
R205 1-216-855-11 METAL CHIP 680K 5% 1/16W
R206 1-216-818-11 METAL CHIP 560 5% 1/16W
R207 1-216-789-11 METAL CHIP 2.2 5% 1/16W
(US, AEP, IT, EE, CND)
R207 1-216-796-11 RES,CHIP 8.2 5% 1/16W
(FR)
R207 1-216-797-11 METAL CHIP 10 5% 1/16W
(E, C&SA, EA, PA, CH, JE)
R209 1-216-850-11 METAL CHIP 270K 5% 1/16W
(US, AEP, IT, FR, EE, CND)
R209 1-216-846-11 METAL CHIP 120K 5% 1/16W
(E, C&SA, EA, PA, CH, JE)
R301 1-216-821-11 METAL CHIP 1K 5% 1/16W
R305 1-216-837-11 METAL CHIP 22K 5% 1/16W
R306 1-216-835-11 METAL CHIP 15K 5% 1/16W
(FX171/FX177)
R306 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(FX173)
R308 1-216-835-11 METAL CHIP 15K 5% 1/16W
R320 1-216-841-11 METAL CHIP 47K 5% 1/16W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R322 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R601 1-216-857-11 METAL CHIP 1M 5% 1/16W
R602 1-216-857-11 METAL CHIP 1M 5% 1/16W
R603 1-216-857-11 METAL CHIP 1M 5% 1/16W
R604 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R605 1-216-821-11 METAL CHIP 1K 5% 1/16W
R606 1-216-845-11 METAL CHIP 100K 5% 1/16W
R607 1-216-833-11 METAL CHIP 10K 5% 1/16W
R608 1-216-821-11 METAL CHIP 1K 5% 1/16W
R609 1-216-821-11 METAL CHIP 1K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-362-11 RES, VAR, CARBON (VOLUME)
RV601 1-238-663-11 RES, ADJ, CARBON 4.7K
< SWITCH >
S302 1-762-917-11 SWITCH, DETECTION (SMALL TYPE) (POWER)
S303 1-692-298-11 SWITCH, SLIDE (FM MODE/TAPE SELECTOR)
S304 1-692-299-11 SWITCH, SLIDE (FUNCTION)
S305 1-692-298-11 SWITCH, SLIDE (AVLS)
< TRANSFORMER >
T1 1-404-949-11 TRANSFORMER, IF
< THERMISTOR >
TH601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X2 1-767-733-71 FILTER ASSY, CERAMIC 10.7MHz
************************************************************
MISCELLANEOUS
**************
10 1-475-439-11 MEGA BASS UNIT (SWITCH) (FX171/FX177)
10 1-475-440-11 MEGA BASS UNIT (ROTARY) (FX173)
HP901 1-667-291-11 HEAD FLEXIBLE BOARD (W/PLAYBACK HEAD)
M901 1-763-073-11 MOTOR (REEL/CAPSTAN) (PULLEY)
************************************************************
MAIN
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
