— 5 —
3-3. AUDIO BOARD REMOVAL
3-4. CASSETTE LID ASSY REMOVAL
7 AUDIO board
2 Remove solder
3 Remove solder
1 Screw (M1.7 × 3)
4 Flexible board
5
6
2 Screw (M1.4 × 2)
5 Cassette lid assy
3 Screw (M1.4 × 2)
1 OPEN button
4
