38
SECTION 8
ELECTRICAL PARTS LIST
KEY
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
KEY BOARD
**********
1-694-508-11 CONDUCTIVE BOARD, CONNECTION
* 3-030-824-01 PLATE, LIGHT GUIDE
* 3-030-825-01 HOLDER (LCD)
* 3-030-839-01 SHEET (REFLECTOR)
* 3-030-840-01 PLATE (B), GROUND
< CAPACITOR >
C952 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C953 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C954 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C955 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C956 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
< CONNECTOR >
CNP901 1-785-773-11 PIN, CONNECTOR 15P
< DIODE >
D902 8-719-056-82 DIODE UDZ-TE-17-6.2B
D903 8-719-056-82 DIODE UDZ-TE-17-6.2B
D904 8-719-056-82 DIODE UDZ-TE-17-6.2B
D951 8-719-976-99 DIODE UDZ-TE-17-5.1B
< IC >
IC901 8-759-366-34 IC LC75824E
< LIQUID CRYSTAL DISPLAY >
LCD901 1-803-497-11 DISPLAY PANEL, LIQUID CRYSTAL
< SWITCH >
LSW901 1-771-609-11 SWITCH, TACTILE (WITH LED) (OFF) (GREEN)
LSW901 1-771-882-21 SWITCH, TACTILE (WITH LED) (OFF) (AMBER)
LSW902 1-762-617-21 SWITCH, KEY BOARD (WITH LED) (SOURCE)
(AMBER)
LSW902 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SOURCE)
(GREEN)
LSW903 1-762-617-21 SWITCH, KEY BOARD (WITH LED)
(MODE, o) (AMBER)
LSW903 1-762-619-21 SWITCH, KEY BOARD (WITH LED)
(MODE, o) (GREEN)
LSW905 1-762-617-21 SWITCH, KEY BOARD (WITH LED) (SOUND)
(AMBER)
LSW905 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SOUND)
(GREEN)
LSW906 1-771-609-11 SWITCH, TACTILE (WITH LED) (SHIFT)
(GREEN)
LSW906 1-771-882-21 SWITCH, TACTILE (WITH LED) (SHIFT)
(AMBER)
LSW921 1-762-617-21 SWITCH, KEY BOARD (WITH LED) (Z)
(AMBER)
LSW921 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (Z)
(GREEN)
LSW922 1-762-617-21 SWITCH, KEY BOARD (WITH LED)
(3100R: PRST –/C33R: PRESET –, DISC –)
(AMBER)
LSW922 1-762-619-21 SWITCH, KEY BOARD (WITH LED)
(3100R: PRST –/C33R: PRESET –, DISC –)
(GREEN)
LSW923 1-762-617-21 SWITCH, KEY BOARD (WITH LED)
(3100R: PRST +/C33R: PRESET +, DISC +)
(AMBER)
LSW923 1-762-619-21 SWITCH, KEY BOARD (WITH LED)
(3100R: PRST +/C33R: PRESET +, DISC +)
(GREEN)
LSW925 1-762-617-21 SWITCH, KEY BOARD (WITH LED) (AF/TA)
(AMBER)
LSW925 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (AF/TA)
(GREEN)
LSW926 1-762-617-21 SWITCH, KEY BOARD (WITH LED) (PTY)
(AMBER)
LSW926 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (PTY)
(GREEN)
LSW927 1-762-617-21 SWITCH, KEY BOARD (WITH LED) (DSPL)
(AMBER)
LSW927 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (DSPL)
(GREEN)
LSW928 1-771-609-11 SWITCH, TACTILE (WITH LED) (6) (GREEN)
LSW928 1-771-882-21 SWITCH, TACTILE (WITH LED) (6) (AMBER)
LSW929 1-771-609-11 SWITCH, TACTILE (WITH LED) (5) (GREEN)
LSW929 1-771-882-21 SWITCH, TACTILE (WITH LED) (5) (AMBER)
LSW930 1-771-609-11 SWITCH, TACTILE (WITH LED) (4, t)
(GREEN)
LSW930 1-771-882-21 SWITCH, TACTILE (WITH LED) (4, t)
(AMBER)
LSW931 1-771-609-11 SWITCH, TACTILE (WITH LED)
(3, PLAY MODE) (GREEN)
LSW931 1-771-882-21 SWITCH, TACTILE (WITH LED)
(3, PLAY MODE) (AMBER)
When indicating parts by reference
number, please include the board.
• Abbreviation
AMBER : Amber illumination type
GREEN : Green illumination type
