Sony XR-C33R Service Manual

39
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
KEY MAIN
LSW932 1-771-609-11 SWITCH, TACTILE (WITH LED) (2, SET UP)
(GREEN)
LSW932 1-771-882-21 SWITCH, TACTILE (WITH LED) (2, SET UP)
(AMBER)
LSW933 1-771-609-11 SWITCH, TACTILE (WITH LED) (1, T)
(GREEN)
LSW933 1-771-882-21 SWITCH, TACTILE (WITH LED) (1, T)
(AMBER)
< PILOT LAMP >
PL901 1-517-633-21 LAMP, PILOT (LCD BACK LIGHT)
PL902 1-517-633-21 LAMP, PILOT (LCD BACK LIGHT)
< TRANSISTOR >
Q945 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R901 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R902 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R903 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R904 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R905 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R906 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R907 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R921 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R922 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R923 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R924 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R925 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R926 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R927 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R928 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R929 1-216-667-11 METAL CHIP 4.7K 0.5% 1/10W
R930 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R931 1-208-806-11 RES, CHIP 10K 2% 1/10W
R932 1-208-810-11 RES, CHIP 15K 2% 1/10W
R951 1-216-041-00 METAL CHIP 470 5% 1/10W
R953 1-216-121-00 RES, CHIP 1M 5% 1/10W
R954 1-216-049-11 RES, CHIP 1K 5% 1/10W
R955 1-216-049-11 RES, CHIP 1K 5% 1/10W
R956 1-216-049-11 RES, CHIP 1K 5% 1/10W
R957 1-216-109-00 METAL CHIP 330K 5% 1/10W
R961 1-216-021-00 METAL CHIP 68 5% 1/10W
(GREEN)
R961 1-216-029-00 METAL CHIP 150 5% 1/10W
(AMBER)
R963 1-216-033-00 METAL CHIP 220 5% 1/10W
(GREEN)
R963 1-216-037-00 METAL CHIP 330 5% 1/10W
(AMBER)
R965 1-216-033-00 METAL CHIP 220 5% 1/10W
(GREEN)
R965 1-216-037-00 METAL CHIP 330 5% 1/10W
(AMBER)
R967 1-216-033-00 METAL CHIP 220 5% 1/10W
(GREEN)
R967 1-216-037-00 METAL CHIP 330 5% 1/10W
(AMBER)
R969 1-216-033-00 METAL CHIP 220 5% 1/10W
(GREEN)
R969 1-216-037-00 METAL CHIP 330 5% 1/10W
(AMBER)
R975 1-216-029-00 METAL CHIP 150 5% 1/10W
(GREEN)
R975 1-216-037-00 METAL CHIP 330 5% 1/10W
(AMBER)
R977 1-216-037-00 METAL CHIP 330 5% 1/10W
R981 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R982 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R983 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R984 1-216-081-00 METAL CHIP 22K 5% 1/10W
R990 1-216-295-00 SHORT 0
R991 1-216-295-00 SHORT 0
< ROTARY ENCODER >
RE901 1-475-014-11 ENCODER, ROTARY (VOLUME/BASS/TREBLE/
BALANCE/FADER CONTROL)
< SWITCH >
S901 1-771-290-11 SWITCH, SLIDE
(SEEK/AMS, > M +, . m –)
S981 1-762-937-11 SWITCH, ROTARY (D-BASS)
**************************************************************
* A-3326-071-A MAIN BOARD, COMPLETE (3100R)
* A-3326-073-A MAIN BOARD, COMPLETE (C33R: AMBER)
* A-3326-106-A MAIN BOARD, COMPLETE (C33R: GREEN)
*********************
* 3-019-147-01 BRACKET (IC) (M)
* 3-031-050-02 HEAT SINK (C33R)
* 3-031-056-01 HEAT SINK (3100R)
* 3-031-828-01 BRACKET (REG. IC)
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C1 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C2 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C3 1-124-233-11 ELECT 10uF 20% 16V
C4 1-124-233-11 ELECT 10uF 20% 16V
C5 1-124-233-11 ELECT 10uF 20% 16V
C6 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C7 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C8 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C10 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C11 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C12 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C13 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C14 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C15 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C16 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C17 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C18 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C19 1-163-059-00 CERAMIC CHIP 0.01uF 10% 50V
C20 1-124-234-00 ELECT 22uF 20% 16V
C21 1-163-091-00 CERAMIC CHIP 8PF 50V
C22 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C23 1-163-087-00 CERAMIC CHIP 4PF 50V
