Sony XR-C33R Service Manual

40
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
C24 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C25 1-124-233-11 ELECT 10uF 20% 16V
C26 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C27 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C33 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C34 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C51 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C52 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C53 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C54 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C55 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C56 1-124-234-00 ELECT 22uF 20% 16V
C57 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C58 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C59 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C60 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C61 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C62 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C63 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C64 1-124-233-11 ELECT 10uF 20% 16V
C71 1-124-234-00 ELECT 22uF 20% 16V
C73 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C81 1-124-589-11 ELECT 47uF 20% 16V
C82 1-124-234-00 ELECT 22uF 20% 16V
C83 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C90 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C91 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C92 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C93 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C94 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C95 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C96 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C97 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C98 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C101 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C102 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C105 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C107 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C108 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C110 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C111 1-126-163-11 ELECT 4.7uF 20% 50V
C121 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C122 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C123 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C135 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C141 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C33R)
C142 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(C33R)
C151 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C152 1-124-257-00 ELECT 2.2uF 20% 50V
C153 1-124-257-00 ELECT 2.2uF 20% 50V
C171 1-126-163-11 ELECT 4.7uF 20% 50V
C173 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C174 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C181 1-126-163-11 ELECT 4.7uF 20% 50V
C182 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C33R)
C183 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C184 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C201 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C202 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C205 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C207 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C208 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C210 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C211 1-126-163-11 ELECT 4.7uF 20% 50V
C235 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C241 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C33R)
C242 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(C33R)
C251 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C252 1-124-257-00 ELECT 2.2uF 20% 50V
C253 1-124-257-00 ELECT 2.2uF 20% 50V
C271 1-126-163-11 ELECT 4.7uF 20% 50V
C273 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C274 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C281 1-126-163-11 ELECT 4.7uF 20% 50V
C282 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C33R)
C283 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C284 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C301 1-124-584-00 ELECT 100uF 20% 10V
C302 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C303 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C304 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C305 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C306 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C331 1-124-234-00 ELECT 22uF 20% 16V
C361 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C362 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C363 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C364 1-126-157-11 ELECT 10uF 20% 16V
C365 1-124-234-00 ELECT 22uF 20% 16V
C366 1-126-933-11 ELECT 100uF 20% 16V
C401 1-124-584-00 ELECT 100uF 20% 10V
C402 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C404 1-124-233-11 ELECT 10uF 20% 16V
C405 1-124-234-00 ELECT 22uF 20% 16V
C408 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C502 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C503 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C504 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C505 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C506 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
C507 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C509 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C510 1-124-584-00 ELECT 100uF 20% 10V
C511 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C527 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C601 1-107-885-31 ELECT 3300uF 20% 16V
C602 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C603 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C33R)
C611 1-124-233-11 ELECT 10uF 20% 16V
