Sony XR-C33R Service Manual

41
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
C612 1-124-233-11 ELECT 10uF 20% 16V
C613 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C614 1-107-909-11 ELECT 47uF 20% 16V
C616 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C617 1-136-165-00 MYLAR 0.1uF 5% 50V
C621 1-124-589-11 ELECT 47uF 20% 16V
C622 1-124-257-00 ELECT 2.2uF 20% 50V
C623 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C631 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C632 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C641 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C653 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C654 1-125-701-11 DOUBLE LAYER 0.047F 5.5V
C655 1-126-933-11 ELECT 100uF 20% 16V
C661 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C671 1-126-157-11 ELECT 10uF 20% 16V
C672 1-126-157-11 ELECT 10uF 20% 16V
C673 1-126-157-11 ELECT 10uF 20% 16V
C674 1-126-157-11 ELECT 10uF 20% 16V
C675 1-126-157-11 ELECT 10uF 20% 16V
C676 1-126-157-11 ELECT 10uF 20% 16V
C701 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(C33R)
C702 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C703 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(C33R)
C704 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
(C33R)
< CONNECTOR >
CN301 1-766-260-11 CONNECTOR, FFC/FPC (ZIF) 7P
* CN302 1-506-995-11 PIN, CONNECTOR (PC BOARD) 13P
CN500 1-785-772-11 PLUG, CONNECTOR 15P
CN601 1-785-761-11 PIN, CONNECTOR (ISO) (POWER)
CN701 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN)
(C33R)
CNJ151 1-774-699-12 JACK, PIN 4P (BUS AUDIO IN, AUDIO OUT)
(C33R)
< DIODE >
D1 8-719-991-65 DIODE SB02W03C-TB
D61 8-719-422-12 DIODE UDZ-TE-17-3.9B
D71 8-719-158-15 DIODE UDZ-TE-17-5.6B
D81 8-719-977-28 DIODE UDZ-TE-17-10B
D90 8-719-073-01 DIODE MA111-TX
D91 8-719-073-01 DIODE MA111-TX
D92 8-719-976-99 DIODE UDZ-TE-17-5.1B
D93 8-719-422-12 DIODE UDZ-TE-17-3.9B
D361 8-719-977-22 DIODE UDZ-TE-17-9.1B
D362 8-719-911-19 DIODE 1SS119-25TD
D441 8-719-056-82 DIODE UDZ-TE-17-6.2B (C33R)
D481 8-719-056-82 DIODE UDZ-TE-17-6.2B (C33R)
D501 8-719-914-44 DIODE DAP202K-T-146
D551 8-719-056-82 DIODE UDZ-TE-17-6.2B
D552 8-719-056-82 DIODE UDZ-TE-17-6.2B
D553 8-719-056-82 DIODE UDZ-TE-17-6.2B
D554 8-719-056-82 DIODE UDZ-TE-17-6.2B
D555 8-719-056-93 DIODE UDZ-TE-17-18B
D556 8-719-056-82 DIODE UDZ-TE-17-6.2B
D557 8-719-056-82 DIODE UDZ-TE-17-6.2B
D558 8-719-056-82 DIODE UDZ-TE-17-6.2B
D559 8-719-056-82 DIODE UDZ-TE-17-6.2B
D561 8-719-056-82 DIODE UDZ-TE-17-6.2B
D562 8-719-056-82 DIODE UDZ-TE-17-6.2B
D601 8-719-049-38 DIODE 1N5404TU
D602 8-719-056-93 DIODE UDZ-TE-17-18B
D603 8-719-056-93 DIODE UDZ-TE-17-18B (C33R)
D604 8-719-056-82 DIODE UDZ-TE-17-6.2B
D611 8-719-053-18 DIODE 1SR154-400TE-25
D612 8-719-053-18 DIODE 1SR154-400TE-25
D613 8-719-053-18 DIODE 1SR154-400TE-25
D614 8-719-053-18 DIODE 1SR154-400TE-25
D615 8-719-053-18 DIODE 1SR154-400TE-25
D616 8-719-053-18 DIODE 1SR154-400TE-25
D617 8-719-053-18 DIODE 1SR154-400TE-25
D618 8-719-053-18 DIODE 1SR154-400TE-25
D621 8-719-422-12 DIODE UDZ-TE-17-3.9B
D622 8-719-073-01 DIODE MA111-TX
D623 8-719-977-22 DIODE UDZ-TE-17-9.1B
D624 8-719-073-01 DIODE MA111-TX
D631 8-719-158-49 DIODE UDZ-TE-17-12B
D651 8-719-911-19 DIODE 1SS119-25TD
D653 8-719-073-01 DIODE MA111-TX
D661 8-719-073-01 DIODE MA111-TX
D662 8-719-056-85 DIODE UDZ-TE-17-8.2B
D671 8-719-970-02 DIODE 1SR139-400T-32 (C33R)
D672 8-719-970-02 DIODE 1SR139-400T-32
D673 8-719-970-02 DIODE 1SR139-400T-32
D674 8-719-970-02 DIODE 1SR139-400T-32 (C33R)
D701 8-719-056-93 DIODE UDZ-TE-17-18B
D702 8-719-017-62 DIODE MA8068-L-TX (C33R)
D703 8-719-056-82 DIODE UDZ-TE-17-6.2B (C33R)
D704 8-719-056-93 DIODE UDZ-TE-17-18B (C33R)
D705 8-719-056-93 DIODE UDZ-TE-17-18B (C33R)
D706 8-719-072-70 DIODE MA2ZD14001S0 (C33R)
D707 8-719-056-84 DIODE UDZ-TE-17-7.5B (3100R)
< FERRITE BEAD >
FB501 1-414-233-22 FERRITE BEAD INDUCTOR
< IC >
IC1 8-759-586-59 IC TB2118F-EL-S
IC51 8-759-650-68 IC SAA6588T/V2-118
IC90 8-759-909-71 IC BA4558F
IC301 8-752-079-78 IC CXA2509AQ-T4
IC361 8-759-823-87 IC LB1638M
IC401 8-759-572-10 IC TDA7462D013TR
IC501 8-759-659-11 IC MB90574PMT-G-222-BND
IC611 8-759-486-44 IC TDA7386
IC652 8-759-574-61 IC XC61AN4302MR
IC671 8-759-347-50 IC BA3918-V3
IC701 8-759-449-89 IC BA8270F-E2 (C33R)
