Sony XR-C33R Service Manual

42
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
< JACK >
J1 1-764-808-21 JACK (ANT) (FM/AM ANTENNA)
J501 1-566-822-41 JACK (REMOTE IN)
< SHORT >
JC1 1-216-295-00 SHORT 0
JC301 1-216-295-00 SHORT 0
JC503 1-216-295-00 SHORT 0
< COIL >
L1 1-410-989-11 INDUCTOR CHIP 0.47uH
L51 1-410-509-11 INDUCTOR 10uH
L601 1-411-669-21 CHOKE COIL
< TRANSISTOR >
Q51 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q61 8-729-921-25 TRANSISTOR FMC2-T148
Q71 8-729-015-11 TRANSISTOR 2SD1802FAST-TL
Q81 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q82 8-729-921-25 TRANSISTOR FMC2-T148
Q90 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q121 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q151 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q171 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q181 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q251 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q271 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q281 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q361 8-729-015-11 TRANSISTOR 2SD1802FAST-TL
Q362 8-729-921-25 TRANSISTOR FMC2-T148
Q364 8-729-106-60 TRANSISTOR 2SB1132-T100-R
Q365 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q621 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q622 8-729-021-94 FET 2SK1657-T1B
Q631 8-729-423-99 TRANSISTOR 2SD2137-OP-TA
Q633 8-729-921-25 TRANSISTOR FMC2-T148
Q651 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q652 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q661 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q701 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q702 1-801-806-11 TRANSISTOR DTC144EKA-T146 (3100R)
Q703 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
(3100R)
< RESISTOR >
R1 1-216-049-11 RES, CHIP 1K 5% 1/10W
R2 1-216-029-00 METAL CHIP 150 5% 1/10W
R3 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R6 1-216-073-00 METAL CHIP 10K 5% 1/10W
R7 1-216-073-00 METAL CHIP 10K 5% 1/10W
R8 1-216-073-00 METAL CHIP 10K 5% 1/10W
R11 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R12 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R13 1-216-025-00 RES, CHIP 100 5% 1/10W
R14 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R15 1-216-025-00 RES, CHIP 100 5% 1/10W
R16 1-216-073-00 METAL CHIP 10K 5% 1/10W
R51 1-216-097-00 RES, CHIP 100K 5% 1/10W
R52 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R53 1-216-113-00 METAL CHIP 470K 5% 1/10W
R54 1-216-049-11 RES, CHIP 1K 5% 1/10W
R55 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R56 1-216-041-00 METAL CHIP 470 5% 1/10W
R57 1-216-037-00 METAL CHIP 330 5% 1/10W
R58 1-216-037-00 METAL CHIP 330 5% 1/10W
R59 1-216-001-00 METAL CHIP 10 5% 1/10W
R60 1-216-009-00 RES, CHIP 22 5% 1/10W
R61 1-216-037-00 METAL CHIP 330 5% 1/10W
R62 1-216-045-00 METAL CHIP 680 5% 1/10W
R71 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R81 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R90 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R91 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R92 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R93 1-216-097-00 RES, CHIP 100K 5% 1/10W
R94 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R95 1-216-121-00 RES, CHIP 1M 5% 1/10W
R96 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R97 1-216-049-11 RES, CHIP 1K 5% 1/10W
R101 1-216-097-00 RES, CHIP 100K 5% 1/10W
R102 1-216-097-00 RES, CHIP 100K 5% 1/10W
R105 1-216-109-00 METAL CHIP 330K 5% 1/10W
R106 1-216-077-00 RES, CHIP 15K 5% 1/10W
R107 1-216-079-00 METAL CHIP 18K 5% 1/10W
R108 1-216-073-00 METAL CHIP 10K 5% 1/10W
R109 1-216-077-00 RES, CHIP 15K 5% 1/10W
R110 1-216-041-00 METAL CHIP 470 5% 1/10W
R121 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R141 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(C33R)
R142 1-216-073-00 METAL CHIP 10K 5% 1/10W
(C33R)
R151 1-216-077-00 RES, CHIP 15K 5% 1/10W
R152 1-216-085-00 METAL CHIP 33K 5% 1/10W
R171 1-216-033-00 METAL CHIP 220 5% 1/10W
R172 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R173 1-216-089-00 RES, CHIP 47K 5% 1/10W
R174 1-216-121-00 RES, CHIP 1M 5% 1/10W
R181 1-216-033-00 METAL CHIP 220 5% 1/10W
R182 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R183 1-216-089-00 RES, CHIP 47K 5% 1/10W
R184 1-216-121-00 RES, CHIP 1M 5% 1/10W
R201 1-216-097-00 RES, CHIP 100K 5% 1/10W
R202 1-216-097-00 RES, CHIP 100K 5% 1/10W
R205 1-216-109-00 METAL CHIP 330K 5% 1/10W
R206 1-216-077-00 RES, CHIP 15K 5% 1/10W
R207 1-216-079-00 METAL CHIP 18K 5% 1/10W
R208 1-216-073-00 METAL CHIP 10K 5% 1/10W
R209 1-216-077-00 RES, CHIP 15K 5% 1/10W
R210 1-216-041-00 METAL CHIP 470 5% 1/10W
R241 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(C33R)
R242 1-216-073-00 METAL CHIP 10K 5% 1/10W
(C33R)
R251 1-216-077-00 RES, CHIP 15K 5% 1/10W
