Sony XR-C33R Service Manual

43
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
R252 1-216-085-00 METAL CHIP 33K 5% 1/10W
R271 1-216-033-00 METAL CHIP 220 5% 1/10W
R272 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R273 1-216-089-00 RES, CHIP 47K 5% 1/10W
R274 1-216-121-00 RES, CHIP 1M 5% 1/10W
R281 1-216-033-00 METAL CHIP 220 5% 1/10W
R282 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R283 1-216-089-00 RES, CHIP 47K 5% 1/10W
R284 1-216-121-00 RES, CHIP 1M 5% 1/10W
R301 1-208-812-11 RES, CHIP 18K 2% 1/10W
R302 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R303 1-216-077-00 RES, CHIP 15K 5% 1/10W
R304 1-216-105-00 RES, CHIP 220K 5% 1/10W
R305 1-216-001-00 METAL CHIP 10 5% 1/10W
R361 1-216-049-11 RES, CHIP 1K 5% 1/10W
R362 1-249-389-11 CARBON 4.7 5% 1/4W
R363 1-249-389-11 CARBON 4.7 5% 1/4W
R364 1-216-073-00 METAL CHIP 10K 5% 1/10W
R365 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R504 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R505 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R506 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R508 1-216-073-00 METAL CHIP 10K 5% 1/10W
R509 1-216-097-00 RES, CHIP 100K 5% 1/10W
R511 1-216-097-00 RES, CHIP 100K 5% 1/10W
R512 1-216-097-00 RES, CHIP 100K 5% 1/10W
R518 1-216-097-00 RES, CHIP 100K 5% 1/10W
R519 1-216-097-00 RES, CHIP 100K 5% 1/10W
R520 1-216-097-00 RES, CHIP 100K 5% 1/10W
R522 1-216-097-00 RES, CHIP 100K 5% 1/10W
R523 1-216-097-00 RES, CHIP 100K 5% 1/10W
R524 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R525 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R526 1-216-097-00 RES, CHIP 100K 5% 1/10W
R527 1-208-806-11 RES, CHIP 10K 0.5% 1/10W
R529 1-216-073-00 METAL CHIP 10K 5% 1/10W
R535 1-216-097-00 RES, CHIP 100K 5% 1/10W
R536 1-216-097-00 RES, CHIP 100K 5% 1/10W
(C33R: GREEN)
R537 1-216-097-00 RES, CHIP 100K 5% 1/10W
(3100R/C33R: AMBER)
R539 1-216-097-00 RES, CHIP 100K 5% 1/10W
R540 1-216-097-00 RES, CHIP 100K 5% 1/10W
R542 1-216-089-00 RES, CHIP 47K 5% 1/10W
R551 1-208-806-11 RES, CHIP 10K 0.5% 1/10W
R552 1-208-806-11 RES, CHIP 10K 0.5% 1/10W
R553 1-216-025-00 RES, CHIP 100 5% 1/10W
R554 1-216-025-00 RES, CHIP 100 5% 1/10W
R555 1-216-097-00 RES, CHIP 100K 5% 1/10W
R556 1-216-097-00 RES, CHIP 100K 5% 1/10W
R558 1-216-025-00 RES, CHIP 100 5% 1/10W
R559 1-216-025-00 RES, CHIP 100 5% 1/10W
R560 1-216-025-00 RES, CHIP 100 5% 1/10W
R561 1-216-025-00 RES, CHIP 100 5% 1/10W
R611 1-216-049-11 RES, CHIP 1K 5% 1/10W
R612 1-216-049-11 RES, CHIP 1K 5% 1/10W
R621 1-216-017-00 RES, CHIP 47 5% 1/10W
R622 1-216-295-00 SHORT 0
R623 1-216-073-00 METAL CHIP 10K 5% 1/10W
R624 1-216-049-11 RES, CHIP 1K 5% 1/10W
R631 1-249-383-11 CARBON 1.5 5% 1/6W
R632 1-249-383-11 CARBON 1.5 5% 1/6W
R633 1-249-383-11 CARBON 1.5 5% 1/6W
R634 1-249-383-11 CARBON 1.5 5% 1/6W
R636 1-216-037-00 METAL CHIP 330 5% 1/10W
R641 1-216-097-00 RES, CHIP 100K 5% 1/10W
R642 1-216-113-00 METAL CHIP 470K 5% 1/10W
R651 1-216-113-00 METAL CHIP 470K 5% 1/10W
R652 1-216-097-00 RES, CHIP 100K 5% 1/10W
R653 1-208-806-11 RES, CHIP 10K 0.5% 1/10W
R654 1-216-073-00 METAL CHIP 10K 5% 1/10W
R655 1-216-025-00 RES, CHIP 100 5% 1/10W
R656 1-216-025-00 RES, CHIP 100 5% 1/10W
R661 1-249-421-11 CARBON 2.2K 5% 1/4W
R662 1-216-081-00 METAL CHIP 22K 5% 1/10W
R663 1-216-089-00 RES, CHIP 47K 5% 1/10W
R664 1-216-089-00 RES, CHIP 47K 5% 1/10W
R683 1-216-089-00 RES, CHIP 47K 5% 1/10W
R701 1-216-017-00 RES, CHIP 47 5% 1/10W
(C33R)
R702 1-216-073-00 METAL CHIP 10K 5% 1/10W
(C33R)
R703 1-216-025-00 RES, CHIP 100 5% 1/10W
(C33R)
R704 1-216-025-00 RES, CHIP 100 5% 1/10W
(C33R)
R705 1-216-089-00 RES, CHIP 47K 5% 1/10W
(3100R)
R706 1-216-089-00 RES, CHIP 47K 5% 1/10W
(3100R)
R708 1-216-097-00 RES, CHIP 100K 5% 1/10W
(3100R)
R712 1-216-089-00 RES, CHIP 47K 5% 1/10W
(3100R)
< COMPOSITION CIRCUIT BLOCK >
RB601 1-233-413-11 RES, CHIP NETWORK 2.2K (3216)
RB602 1-233-810-21 RES, NETWORK 100K (3216)
RB701 1-233-810-21 RES, NETWORK 100K (3216) (3100R)
< VARIABLE RESISTOR >
RV1 1-223-836-11 RES, ADJ, CARBON 220K
< SWITCH >
S501 1-571-478-11 SWITCH, SLIDE (POWER SELECT)
S503 1-692-431-21 SWITCH, TACTILE (RESET)
< THERMISTOR >
TH701 1-801-792-21 THERMISTOR, POSITIVE (C33R)
< TUNER >
TU1 1-693-440-23 TUNER UNIT (FM/AM TUNER UNIT)
< VIBRATOR >
X1 1-781-246-21 VIBRATOR, CRYSTAL (10.25MHz)
X51 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz)
