[Table 1D-A. MAXI Type Standard & Low NOx Burner]
Model
Dimension[mm] Boiler Dimension[mm]
B (B’) C (C’) E F G W Z U H P M
MAXI 5 90 140 300 - 200 150 90 320 150 105 100 150 2-M10
MAXI 8 150
220 360 - 280 150 102 330 150 180 110 150 2-M10
MAXI 10 150
220 360 - 280 150 102 330 150 180 110 150 2-M10
MAXI 16 150
220 380 390 280 150 114 350 170 180 120 150 2-M10
MAXI 20S
150
220 380 - 170 240 114 400 170 135 120 150 2-M10
MAXI 20 170
220 470 - 310 260 140 330 215 210 150 190 2-M10
MAXI 25 170
220 470 480 310 260 140 330 215 210 150 190 2-M10
MAXI 32S(AB)
170
220 490 - 310 260 140 330 215 210 150 190 2-M10
MAXI 32 170
220 570 650 360 260 140 480 220 240 150 190 2-M10
MAXI 25 LX
170
- 470 480 310 260 121 330 215 210 130 190 2-M10
MAXI 32 LX
220
- 530 610 350 260 140 480 220 240 150 190 2-M10
B – Standard Tube Type, (B’) – Long Tube Type
C – Gas filter (low gas pressure, P ≤ 3.3kPa), (C’) – Governor (high gas pressure, P > 3.3kPa)
