Sophos APX Series User Manual

19APX 320/530/740
Operating Instructions
5. Align the Access Point (with fix-plate) via the key holes to the
main bracket and push it to the end in the sliding-slot.
Suspend mount
For suspend mounting, please use the “suspend mounting kit” which is available as an
option from your Sophos partner. The suspend mounting kit must be installed by a skilled
installer.
The kit consists of the following components:
4 ring screws
Anchor feature
Wire gripper
Suspend wire
Secure clip
4 suspend wires with anchor
features and secure clips
Mounting instructions
Screw the 4 supplied ring-screws (M3) into the bracket holes on the rear of the access
point.

Sophos APX Series Specifications

General

Wi-Fi Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz, 5 GHz
MIMO	2x2
Ethernet Ports	1 or more Gigabit Ethernet ports
Power over Ethernet (PoE)	802.3at PoE+
Security	WPA3, WPA2, WPA, WEP, 802.1X, AES, TKIP
Management	Sophos Central
Mounting	Ceiling, wall
Operating Temperature	0°C to 40°C (32°F to 104°F)
Model	APX 320, APX 320X, APX 530, APX 740, APX 940, APX 530X
