Sorensen DCS100-12E - Table 5-4 DCS 1.2 Kw Parts Lists by Model Number

Parts Lists Sorensen DCS Series 1kW and 1.2kW Supplies
5-4 M362500-01 Rev H
Model
Final
Assembly
Mother PCB
Assembly
Front Panel
PCB
Assembly
Output PCB
Assembly
Rectifier
PCB
Assembly
DCS8-140E
5362500-008
5362462-008
5360801-01
1066830-008
N/A
DCS10-120E
5362500-010
5362462-010
5360801-01
1066830-008
N/A
DCS20-60E
5362500-020
5362462-020
5360801-02
1066830-020
N/A
DCS33-36E
5362500-033
5362462-033
5360801-02
1066830-01
5360726-01
DCS40-30E
5362500-040
5362462-040
5360801-02
1066830-01
5360726-02
DCS50-24E
5362500-050
5362462-050
5360801-02
1066830-01
5360726-02
DCS60-20E
5362500-060
5362462-060
5360801-02
1066830-01
5360726-03
DCS80-15E
5362500-080
5362462-080
5360801-02
1066830-080
5360726-04
DCS100-12E
5362500-100
5362462-100
5360801-02
1066830-100
5360726-04
DCS150-8E
5362500-150
5362462-150
5360801-01
N/A
N/A
DCS300-4E
5362500-300
5362462-300
5360801-01
N/A
N/A
DCS600-2E
5362500-600
5362462-600
5360801-01
N/A
N/A
Table 5–4 DCS 1.2kW Parts Lists by Model Number
