28
ELECTRIC PANEL
BSS-134
CHAP.- 8
- [1] Black Push Button - PLIERS HORIZONTAL - this push button only works when the machine is
set to manual working and when pressed at the same time as push button [7] MANUAL
WORKING.
- pressed once, the two horizontal pliers close and seal (with or without netting/fi lm),
- pressed a second time, the horizontal pliers open.
- [2] Red button - NET UNWINDING JOGGING STEP STOP IN PHASE -
- if pressed during manual working, the machine unwinds netting and strip for one machine
step
- if pressed during automatic working, the machine memorises and stops in phase, disa-
bling the AUTOMATIC WORKING.
- [3] RED MUSHROOM-SHAPED STOP BUTTON - This button stops the machine immediately.
After being pressed a counterclockwise rotation is necessary to unlock it without provoking
the machine’s new startup.
N.B. = use this button in case of emergency only.
- [4] RED LIGHT -
fi xed = indicates the machine stopped because:
- the RED MUSHROOM BUTTON [3] intervened (see fi g.1 chap.8).
- the doors are opened.
blinking = indicates a failure or an information message
N.B. = TO RECOGNISE THE TYPE OF FAULT (WHEN RED LUMINOUS LAMP [7] (see
fi g.1 chap.8) IS ON AND FLASHING OR PERMANENT) PRESS KEY IN THE DISPLAY
TO HAVE FURTHER INFORMATION (see table 1.1 chap.8).
When on and quickly fl ashing = indicates:
- the “F1 RESET PROGRAM” control on page 9 of the display has been pressed,
- the “F2 RESET DATA” control on page 9 of the display has been pressed.
