29
ELECTRIC PANEL
BSS-134
CHAP.- 8
ST FN
ST
°C
ALM
OUT
LOW HIGH
SP
ST
FN
- [5] VERTICAL SEALING - It adjusts the sealing temperature to the type of material used and the
current room temperature.
The recommended temperature ranges from 240 to 280°C.
The machine is READY FOR USE when the thermoregulator displays the temperature
that was previously set.
To CHANGE THE PREVIOUSLY SET TEMPERATURE proceed as follows:
1) Press, for more than 3 seconds, the or push-button; the set point value,
will be displayed and it will start to change.
2) Using the and push-buttons, it is possible to set the desired value.
3) When the desired value is reached, do not press any push-button for more than 3 sec-
onds, the new set point will become operative after 3 seconds from the last push-button
being pressed.
If during this procedure, there is no interest in storing the new value, press the push-
button; the instrument automatically returns to the normal display mode without having
saved the new set point.
To display the PROGRAMMED SET POINT VALUE press the push-button.
The display will show the set point value and the decimal point of the last signifi cant
(see ) digit will fl ash to indicate that the number shown is the set point value.
To come back to display the measured value, press the push-button again.
For further information on the thermoregulator, please refer to the manufacturer’s manual
the electric panel is supplied with.
