5
TECHNICAL SPECIFICATIONS
BSS-134
CHAP.- 2
2.1 General safety notes
The functioning of the machine is subject to general safety principles used in industrial plants.
In particular, given the typical use conditions for this machine, the following prescriptions must be
followed:
A) The protection devices must never be removed or made ineffi cient; in particular, no safety switch
must ever be short-circuit.
When carrying out maintenance work on the machine, it may be necessary to temporarily deactivate
the safety devices, this operation must be carried out only by authorised and adequately trained
staff.
B) It is forbidden to carry out adjustments or format change if the machine is started.
C) Do not place the hands near the rotary parts of the machine.
Do not wear clothing that might become tangled in moving parts (scarves, neckerchief, rings,
bracelets, watches, etc.).
For those having long hair, use hair clips or caps to hold them.
2.2 Attached documentation
he following documentation has been attached to this manual:
- WIRING DIAGRAM
- PNEUMATIC PLANT LAYOUT
- SPARE PARTS CATALOGUE
- DECLARATION OF CONFORMITY
2.3 Technical introduction
Automatic machine to pack fruit and vegetable.
A roll of the material to form the Vert-bags is positioned in the rear part of the machine. This material
is formed by a part of net and a part of fi lm.
Consequently, the 2 sides of the Vert-bag are made of net and the 2 central parts are made of cu-
stomized fi lm.
The vert-bags are closed by a hot-sealing device
The machine may be equipped with an electronic labeller to apply an adhesive label directly on the
band, or with a thermal transfer system.
Weight of the packs: up to 3 kg. (for green-beans 500 – 750 – 1000 gr.)
Standard Tubes:
- for packs 0,5 to 1,5 kg.: tube diam. 140 and 160 mm.
- for packs 2/2,5 to 3 kg.: tube diam. 180 and 203 mm.
The BSS-134 must be used only for the purpose it was expressly designed for. Any other use is to
be deemed improper and hence unreasonable.
The company Sorma S.p.A. shall not be held liable for any damage due to improper, mistaken or
unreasonable use of the machine, that may be caused to persons and/or animals and/or things.
All restore operations must be carried out only when the machine is disconnected
from the power supply and pneumatic supply.
Therefore, the operator can restore normal operating conditions and remove the anomaly only after
fully disconnecting the machine.
