2.4 Machine description
The machine basically consists of:
A = Electrowelded frame
B = Loading hopper
C = Intake
D = Loading tube
E = Carrier tracks
F = Vertical sealing unit
G = Horizontal sealing unit
H = Tensioner rollers unit
I = Air fi lter unit
L = Self-centring reel unit
M = Electric control board
N = Printer
O = Bridge-breaker unit.
D
C
F
G
E
O
B
A
I
L
M
H
Fig.1 chap.2
