10.2 Pictograms and inspection tables
Tables have been set out for the carrying out of the requested inspection, showing the machine and
certain of its parts, from which it is immediately possible to understand the type of requested check.
Symbols can be seen on the tables, representing the type of check and the periodicity of the control.
10.2.1 Decoding the pictograms
Visual check
check any damages, lubricant leaks, high wear condition.
The visual check operations can expose eyes to a dangerous
situation. It is therefore necessary to wear protection glasses
during these operations.
Aural monitoring
check the presence of unusual noises.
For noise emissions above 85 dBA, it is necessary to wear acoustic
protection devices.
Fastening
check the fastening of the bolts and/or screws holding the components.
It is compulsory to wear protection gloves when carrying out the
fastening operations.
Adjustment
check the position of the component and eventually restore the location.
It is compulsory to wear protection gloves when carrying out the
measuring operations.
