SoundCraft EFX User Manual

35
Soundcraft EFX/EPM User Guide Issue 1210
EFFECTS DATA CHART (EFX only)
No
NAME
ADJUST1 VALUE RANGE
ADJUST2
VALUE RANGE ADJUST3
VALU
E
RANGE
FIXED1 VALUE
FIXED2
VALUE FIXED3
VALUE
ROUTING
1
SMALL HALL
PREDELAY 10ms 0-100ms DECAY 1.0s 0-99 LIVELINESS 75 0-99
2
LARGE HALL
PREDELAY 20ms 0-200ms DECAY 2.0s 0-99 LIVELINESS 35 0-99
3
VOCAL HALL
PREDELAY 10ms 0-200ms DECAY 1.0s 0-99 LIVELINESS 65 0-99
4
DRUM HALL
PREDELAY 10ms 0-100ms DECAY 0.8s 0-99 LIVELINESS 75 0-99
5
SMALL PLATE
PREDELAY 2ms 0-100ms DECAY 1.0s 0-99 LIVELINESS 90 0-99
6
LARGE PLATE
PREDELAY 2ms 0-200ms DECAY 1.75s 0-99 LIVELINESS 90 0-99
7
VOCAL PLATE
PREDELAY 10ms 0-200ms DECAY 1.0s 0-99 LIVELINESS 65 0-99
8
DRUM PLATE
PREDELAY 10ms 0-100ms DECAY 1.0s 0-99 LIVELINESS 75 0-99
9
ROOM
PREDELAY 2ms 0-100ms DECAY 400ms 0-99 LIVELINESS 50 0-99
10
STUDIO
PREDELAY 5ms 0-100ms DECAY 500ms 0-99 LIVELINESS 70 0-99
11
CHAMBER
PREDELAY 0ms 0-100ms DECAY 1.2s 0-99 LIVELINESS 60 0-99
12
AMBIENCE
PREDELAY 0ms 0-100ms DECAY 400ms 0-99 LIVELINESS 70 0-99
13
ARENA
PREDELAY 25ms 0-200ms DECAY 2.75s 0-99 LIVELINESS 60 0-99
14
GATED
PREDELAY 0ms 0-200ms DECAY 300ms 0-99 DIFFUSION 25 0-99
15
KARAOKE
Delay Time 240ms 0-740ms Echo Repeat 44 0-99 Level 50 0-99
16
REVERSE
PREDELAY 200mS 0-200ms DECAY 0 0-99 DIFFUSION 50 0-99
17
SPRING
PREDELAY 0 0-100ms DECAY 1.75s 0-99 BOING 35 0-99
18
STUDIO DELAY
TIME RANGE 275ms 20ms-2.5s FEEDBACK 15 0-99+H DUCK THRESHOLD -6dB -70-0dB
19
DIGITAL DELAY
TIME RANGE 800ms 20ms-5.0s FEEDBACK 20 0-99+H DUCK THRESHOLD -8dB -70-0dB
20
TAPE DELAY
TIME RANGE 500ms 20ms-5.0s FEEDBACK 24 0-99 SMEAR 25 0-99
21
PONG DELAY
TIME RANGE 1.0s 20ms-5.0s FEEDBACK 30 0-99+H TAP RATIO 1:1 0-23
22
MOD DELAY
TIME RANGE 345ms 20ms-2.5s FEEDBACK 25 0-99 MOD DEPTH 75 0-99
23
REVERSE DELAY
TIME RANGE 500ms 20ms-2.5s FEEDBACK 0 0-99 SMEAR 50 0-99
24
CHORUS
SPEED 25 0-99 DEPTH 75 0-99 VOICES 50 0-99
25
FLANGER
SPEED 15 0-99 DEPTH 25 0-99 REGENERATION 80 0-99
26
PHASER
SPEED 25 0-99 DEPTH 75 0-99 REGENERATION 80 0-99
27
TREMELO/PAN
SPEED 40 0-99 DEPTH 80 0-99 PHASE 50 0-99
28
VIBRATO
SPEED
30 0-99
DEPTH
30 0-99
PHASE
80 0-99
29
REV/DEL SHORT
TIME RANGE 275ms 20ms-2.5s FEEDBACK 15 0-99+H DECAY 0.75S 0-99 LIVELINESS 60 PREDELAY 2ms DUCK THRESHOLD -6dB SERIAL : DELAY THEN REVERB
30
REV/DEL LONG
TIME RANGE 800ms 20ms-2.5s FEEDBACK 20 0-99+H DECAY 2.0S 0-99 LIVELINESS 40 PREDELAY 10ms DUCK THRESHOLD -8dB SERIAL : DELAY THEN REVERB
31
PHASE DELAY
TIME RANGE 500ms 20ms-2.5s FEEDBACK 20 0-99+H SPEED 25 0-99 DEPTH 75 REGENERATION 80 DUCK THRESHOLD -8dB SERIAL : DELAY THEN PHASE
32
ROTARY DELAY
TIME RANGE 500ms 20ms-2.5s FEEDBACK 20 0-99+H SPEED 50 0-99 DOPPLER 60 SPREAD 99 DUCK THRESHOLD -8dB SERIAL : DELAY THEN ROTARY
Note +H = repeat hold function (see page 27 1st paragraph)

SoundCraft EFX Specifications

General

Channels quantity	10 channels

Weight and Dimensions

Depth	362 mm
Width	91 mm
Height	330 mm
Weight	4600 g
