SoundCraft EFX User Manual

52
Soundcraft EFX/EPM User Guide Issue 1210
EPM/EFX TYPICAL SPECIFICATIONS
Frequency Response
Mic / Line Input to any Output ...............................................................+/-1.5dB, 20Hz – 20kHz
T.H.D.
Mic Sensitivity -30dBu, +14dBu @ Mix output ....................................................< 0.02% @ 1kHz
Noise
Mic Input E.I.N. (maximum gain) ..........................……….........................-127dBu (150Ω source)
Aux, Mix and Masters (@ 0dB, faders down)..........................................................………< -85dBu
Crosstalk (@ 1kHz)
Channel Mute...................................................................................................................> 96dB
Aux Send Pots Offness......................................................................................................> 86dB
EQ (Mono inputs)
HF ......................................................................................................................12kHz, +/-15dB
MF (swept)...........................................................................................150Hz – 3.5kHz, +/-15dB
LF..........................................................................................................................80Hz, +/-15dB
Q..............................................................................................................................................1.5
EQ (Stereo inputs)
HF ......................................................................................................................12kHz, +/-15dB
MF……………………………………………………...………….............…...................……..720Hz, +/-15dB
LF ........................................................................................................................80Hz, +/-15dB
Power Consumption...............................................................................................Less than 35W
Operating Conditions
Temperature Range....................................................................................................5°C to 40°C
Input & Output Levels
Mic Input .................................................................................................................+15dBu max
Line Input...................................................................................................................+30dBu max
Stereo Input ............................................................................................................+30dBu max
Mix Output ...............................................................................................................+20dBu max
Headphones (@150Ω) ....................................................................................................300mW
Input & Output Impedances
Mic Input ..............................................................................................................................2kΩ
Line Input ...........................................................................................................................10kΩ
Stereo Input ....................................................................................65kΩ (stereo), 35kΩ (mono)
Outputs .............................................................................150Ω (balanced), 75Ω (unbalanced)
E & OE.
Soundcraft reserves the right to change specications without notice.

SoundCraft EFX Specifications

General

Channels quantity	10 channels

Weight and Dimensions

Depth	362 mm
Width	91 mm
Height	330 mm
Weight	4600 g
