SoundCraft Signature 16 User Manual

16, 22, 22MTK User Manual
3.0: INPUTS AND OUTPUTS
INPUTS AND OUTPUTS
3.0: INPUTS AND OUTPUTS
The physical inputs and outputs on the Signature console are varied, and together with the Ghost mic
preamps,dbx®limiting,andHi-Zinputsprovideaexibleschemeforanysourcesyoumight
encounter. To get the most out of the Signature I/O, read this chapter carefully.

SoundCraft Signature 16 Specifications

General

Type	Analog
Channels	16
Mic Preamps	12
Aux Sends	4
Faders	100mm faders
Phantom Power	Yes
Subgroups	4
Headphone Outputs	1 x 1/4"
EQ Bands	3-band
Inputs - Line	8 x 1/4"
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR
Outputs - Other	4 Aux
Main Outputs	2
Monitor Outputs	2 x 1/4"
