SoundCraft Signature 16 User Manual

16, 22, 22MTK User Manual
7.0: USB OPERATION
USB OPERATION
7.0: USB OPERATION
The Soundcraft Signature consoles use USB 2.0 audio streaming for sending and receiving digital
audio. The Signature 16 and 22 consoles have a two-track USB system while the Signature 22MTK
(Multi-Track) uses a 22-channel system for channel direct inputs and outputs, plus a two-channel sys-
tem for the Playback Channel and recording the recording the main LR mix.

SoundCraft Signature 16 Specifications

General

Type	Analog
Channels	16
Mic Preamps	12
Aux Sends	4
Faders	100mm faders
Phantom Power	Yes
Subgroups	4
Headphone Outputs	1 x 1/4"
EQ Bands	3-band
Inputs - Line	8 x 1/4"
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR
Outputs - Other	4 Aux
Main Outputs	2
Monitor Outputs	2 x 1/4"
