8.3: DELAYS & MODULATION
LEXICON FX > DELAYS & MODULATION
8.3: DELAYS & MODULATION
LO FI
Delay with limited bandwidth that degrades the signal in a pleasing way for a crunchy percussion or any where a
lo-fidelity eect will enhance the feel.
Parameter 1: Number Of Repeats
Parameter 2: Delay Time
STUDIO CHORUS
Chorus creates a lush, full sound by combining two or more signals together where one is unaected and the
other signals vary in pitch very slightly over time. Chorus is commonly used to fatten up tracks and to add body
to guitars without colouring the original tone. Chorus can also be used with discretion to thicken a vocal track.
Studio Chorus is a studio-quality chorus with a wide stereo image.
Parameter 1: Modulation Speed
Parameter 2: Modulation Depth
MODERN CHORUS
Dual-voice chorusing that’s both very rich and very smooth.
Parameter 1: Modulation Speed
Parameter 2: Modulation Depth
TREMOLO
A basic stereo amplitude (volume) modulation eect.
Parameter 1: Modulation Speed
Parameter 2: Modulation Depth
ROTARY
Rotary speaker cabinets were designed to provide a majestic vibrato/choir eect for electronic theatre and
church organs. This algorithm emulates the famous Leslie™ speaker with two counter-rotating elements: a
high-frequency horn and a low-frequency rotor with slow and fast speeds.
Parameter 1: Modulation Speed
Parameter 2: Modulation Depth

SoundCraft Signature 16 Specifications

General

Type	Analog
Channels	16
Mic Preamps	12
Aux Sends	4
Faders	100mm faders
Phantom Power	Yes
Subgroups	4
Headphone Outputs	1 x 1/4"
EQ Bands	3-band
Inputs - Line	8 x 1/4"
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR
Outputs - Other	4 Aux
Main Outputs	2
Monitor Outputs	2 x 1/4"
