d INSTALLATION STEP 3 b
WIRING
POWER AND GROUND
To assure maximum output from your REFERENCE Class A amplifier, use high
quality, lowloss power and ground cables. The REFERENCE Class A amplifiers
will accept up to 4 gauge power and ground cables.
Determine from the chart
below the minimum gauge power and ground wire for your application.
ClRCUlT BREAKERS/FUSES
I
up to 10’
I
up to 20’
REFERENCE
I
Soundstream Power40 or
I
Soundstream Power40
Class A 3.0
Power 80
(4 sa.)
(4 or 8 ga.)
REFERENCE
Class A 6.0
Soundstream Power40 or
Power 80
(4 or 8 ga.)
Soundstream Power40
(4 ga.)
EXTERNAL
Like all audio components, the REFERENCE Class A amplifiers must be fused
near the battery. A fuse or circuit breaker must be located within 18” of the battery.
This will prevent a fire in the event of a shorted cable. See the chart below to
determine the correct fuse value.
INTERNAL
The REFERENCE Class A amplifiers are fused with either automotive-type or
Maxi-fuses. In the event of blown power supply fuses, the “Fault” indicator on the
front panel will light. The fuses are accessible either from the front panel of the
amplifier or via a plastic plug on the bottom of the amplifier. See the chart below
to determine the fuse value. Never replace the fuses with a higher value than
what is supplied. This may result in amplifier damage and will void the
warranty!
REFERENCE Class A Amplifier Fuse Values
Amplifier
REFERENCE
Class A 3.0
REFERENCE
Class A 6.0
Amplifier Fuse
30 amp automotive
40 amp
40 amp MAXI-fuse
50 amp
Battery Fuse
14
