I2 dB/OCTAVE
PASSIVE CROSSOVER CHART
12 dB/octave hioh L)ass
FREQ.
80 Hz
100 Hz
130 Hz
200 Hz
280 Hz
400 Hz
600 Hz
800 Hz
1000 Hz
1200 Hz
1800 Hz
4000 Hz
12 dB/octave low Pass
KEY
Ll = high quality (DCR c 1 ohm) inductor/coil
Cl = non-polarized 50 v (or greater) capacitor
2 ohms
Ll Cl
5.5 mH
4.7 mH
3.3 mH
2.2 mH
1.8 mH
1.1 mH
0.75 mH
0.5 mH
0.47 mH
0.33 mH
0.27 mH
0.10 mH
680 pF
560 pF
400 pF
300 pF
200 pF
15opF
IOOpF
68 P
50 d=
44 G=
30 ti
15fi
I
4 ohms
Ll
Cl
11 mH
9.1 mH
6.8 mH
4.7 mH
3.6 mH
2.2 mH
1.5 mH
1.0 mH
0.9 mH
0.75 mH
0.50 mH
0.22 mH
8
330 pF
270 pF
200 pF
15opF
IOOpF
68 P
47 ti
33 @=
27 ti
22 kJ=
15P
6.8 p!=
8 ohms
Ll Cl
22 mH
18 mH
15 mH
9.1 mH
6.8 mH
4.7 mH
3.0 mH
2.0 mH
1.8 mH
1.5 mH
1.0 mH
0.47 mH
18Op!=
15op!=
IOOpF
75 $
50 ti
33 P
28 PJ=
15fi
13PJ=
11 fi
6.6 pF
3.3 pF
