Soundstream Stealth 1200D - Wiring Diagram (2-Channel Mode - Fig 18); Wiring Diagram (High Level Input & Bridged Mode - Fig 19)

4-Ohm to 8-Ohm
Fig 19. STL2.350 / STL2.560 wiring
(High level input & Bridged mode)
Fig 18. STL2.350 / STL2.560 wiring
WIRING DIAGRAM
(2-channel mode)
Source Unit
FUSE
REMOTE signal
RCA
s
ig
na
l
s
CROSSOV ER
2-Ohm to 4-Ohm
CROSSOV ER
2-Ohm to 4-Ohm
Source Unit
FUSE
Speaker signal
ON/OFF
control signal
