Soundstream VRCPAA-106F User Manual

MODE
VRCPAA-106F
4.Front panel Description
Front panel
7
CPAA-70D10F
MODE
11 12 13 14
1
2 3 4 5 6 7 8 10
Front panel
15 16
USB Slot
Base:
10.6 inch TFT LCD
Mic
Build in Microphone.
1
2
3
Bluetooth button
Touch to access to Bluetooth
mode.
4
MENU button
Touch to back to Main menu.
5
MODE button
Touch to select desired mode.
6
Rotary Control
On/Off button
Short press to switch On the
source unit.
Long press to switch Off the
source unit.
In operation, short press to Mute
the sound system, press again
to Un-Mute.
In operation, rotate to adjust the
sound output level.
7
Siri button
When Apple CarPlay or Android
Auto available, hold Siri button
to start the voice control function.
8
button
9
/
Press and hold to seek downward or
upward.
[Disc/USB/SD Music] Press repeatedly to
shift track previous or next for playback.
Press and hold to active various fast rewind
or fast forward speeds for playback.
[Bluetooth Music] Press repeatedly to
shift track previous or next for playback.
17
Press to eject the disc.
Eject Button
11
Insert an extrenal device to this port
in order to have sound output of
that external device through the unit.
AUX in jack
12
Insert or eject the the disc.
Slot-in
13
Insert micro SD for playback.
Micro SD slot
14
Support fast charge USB port.
Fast charging USB port
15
Press to default factory settings.
Reset button
16
Connect USB for digital playback.
Connect your iPhone for Apple
CarPlay.
Connect your Android Phone for
Android Auto.
USB port
9
10
IR Sensor of Remote
IR remote control signal receiving
window.
17
[Radio] Press to select previous/
next preset radio station for
broadcasting.
