44
Advanced Setup Table
Df = Factory Default Setting
Step# Description Pg# Range Df
36 Minutes Between 1st and 2nd Stage 27 0 - 60 Minutes 2
37 Minutes Between 2nd and 3rd Stage 27 0 - 60 Minutes 2
38 Minutes Between 3rd and 4th Stage 27 0 - 60 Minutes 2
39 2nd StageTurnoff Point 27 Deadband, Setpoint Deadband
40 3rd StageTurnoff Point 27 Deadband, Setpoint Deadband
41 4th Stage Turnoff Point 27 Deadband, Setpoint Deadband
42 Fan Program 28 On, Off Off
43 Minutes of Fan Runtime 28 0-60 0
44 Fan Program Start Time 28 12:00A - 12:00A 7:00A
45 Fan Program Stop Time 28 12:00A - 12:00A 9:00A
46 Wired Sensor Type 28 Remote, Supply Remote
47 Control to Temp Source 31 Thermostat, Wired Remote*, Thermostat
Wireless Remote, Average of
Wireless Remotes, Average
Thermostat and Wired Remote*,
Average All Sensors. *Option
only if prior step = “Remote”
48 Wireless Remote to Use 31 list of wifi sensors currently first linked
linked to thermostat. * This sensor in list
step only appears if prior step =
“Wireless Remote”
49 Humidity Only With Heat 29 On, Off Off
50 Fan With Humidity Demand 29 Fan On, Fan Off Fan Off
51 Fan With Dehumidify Demand 29 Fan On, Fan Off Fan Off
52 Humidity Setpoints 29 Auto, Manual Manual
53 Cool To Dehumidify 29 On, Off Off
54 Maximum Dehum Overcool 29 0 - 20 Degrees 2
55 Reheat Operation W/Cool To Dehum. 29 On, Off Off
56 Lockout Heatpump with Outdoor Temp 30 On, Off Off
57 Lockout Temp 30 0 - 75 Degrees 35
58 Lockout Aux Heat with Outdoor Temp 30 On, Off Off
59 Aux Heat Lockout Temp 30 20 - 75 Degrees 75
60 Dualfuel 30 On, Off Off
61 Dualfuel Changeover on Outdoor Temp 31 On, Off Off
62 Dualfuel Balance Point 31 0 - 60 Degrees 35
63 Dualfuel Changeover Delay in Seconds 31 0 - 90 Seconds 30
64 Fan Off Delay 28 0 - 120 Seconds 0
65 F/C 31 Fahrenheit (F), Celsius (C) F
66 Aux Output Polarity 32 Open, Closed Open
cont. next page
