Southwire 10040n - Specifications

15
Specifications
Function Range Resolution Accuracy (% of reading)
AC Voltage
4.000V 1mV
40.00V 10mV
400.0V 100mV
600V 1V
Input impedance: 7.8MΩ
Frequency range: 50 to 400Hz
±1.2% ± 3 digits
±1.5% ± 3 digits
±1.5% ± 3 digits
±2.0% ± 4 digits
DC Voltage
400.0mV 0.1mV
4.000V 1mV
40.00V 10mV
400.0V 100mV
600V 1V
Input impedance: 7.8MΩ
±0.5% ± 2 digits
±1.2% ± 2 digits
±1.5% ± 2 digits
AC Current
400.0uA 0.1uA
4000uA 1uA
40.00mA 10uA
400.0mA 100uA
10A 10mA
Frequency range: 50 to 400 Hz
±1.5% ± 5 digits
±1.8% ± 5 digits
±3.0% ± 7 digits
DC Current
400.0uA 0.1uA
4000uA 1uA
40.00mA 10uA
400.0mA 100uA
10A 10mA
Frequency range: 50 to 400 Hz
±1.0% ± 3 digits
±1.5% ± 3 digits
±2.5% ± 5 digits
16
Specifications
Function Range Resolution Accuracy (% of reading)
Resistance
400.0Ω 0.1Ω
4.000kΩ 1Ω
40.00kΩ 10Ω
400.0kΩ 100Ω
4.000MΩ 1kΩ
40.00MΩ 10kΩ
±1.2% ± 4 digits
±1.0% ± 2 digits
±1.2% ± 2 digits
±2.0% ± 3 digits
Capacitance
40.00nF 10pF
400.0nF 0.1nF
4.000uF 1nF
40.00uF 10nF
100.0uF 0.1uF
±5.0% ± 7 digits
±3.0% ± 5 digits
±5.0% ± 5 digits
Frequency
5.000Hz 0.001Hz
50.00Hz 0.01Hz
500.0Hz 0.1Hz
5.000kHz 1Hz
50.00kHz 10Hz
500.0kHz 100Hz
5.000MHz 1kHz
10MHz 10kHz
Sensitivity: >8V RMS
±1.5% ± 5 digits
±1.2%
±
3 digits
±1.5% ± 4 digits
Duty Cycle 0.1 to 99.9 0.1%
Pulse width: >100us, <100ms;
Frequency width: 5Hz – 150kHz
Sensitivity: >8V RMS
±1.2% ± 2 digits
Temperature
(Type K)
NOTE: Accuracy is stated at 65°F to 83°F (18°C to 28°C) and less than 70% RH.
-20°C~760°C 0.1°C
-4°F~1400°F 0.1°F
±3% ± 9°F/5°C
