Pag.14
Shortening the PTO shaft
Due to the many different types of tractors, it may be necessary to shorten the PTO shaft.
Always refer to the manual of the driveline’s manu-
factures. Read it carefully.
In case shortening is needed, listed below are some basic guide-
lines on performing this modification. Determine how much
length is to be removed, then:
1) Remove plastic protection (both sec-
tions)
2) Cut the excess length of both tubes
3) Deburr and clean the saw-dust off ends
of tubes. Remove packing inside shaft
tubing
1
2
3
