SOYAL
ACCESS CONTROL SYSTEM
®
AR-321 (H) / AR-331 (H) /
AR-721(H) / AR-725 (H) / AR-757 (H)
V140707
AR-321H
B-
A+
B-
A+
B-
A+
Host
CH1
CH2
10
9
8
7
6
5
4
3
2
1
12V
GND
AR-331 (H)
AR-331 (H)
P7
A+
B-
A+
B-
AR-716E
1
2
3
GLED
RLED
BZ
WG 1
WG 0
GND
12V
P7
GND
12V
12V
GND
331 (HB): 125kHz 331 (HD): 13.56MHz
CARD
CARD
5
4
3
2
1
1
1
1
1
1
10
9
1
2
3
4
5
6
7
8
5
4
3
2
1
1
1
1
11
External WG keyboard
Adding and Deleting Tag
M4/M8
Delete All Tags
Input 123456 (or Master Code)
→
29 29
Delete Single Tag
Input 123456 (or Master Code)
→
10 SSSSS EEEEE
[e.g.] Delete User Address: 00058
Enter program mode
→
10 00058 00058
9
9
Delete a batch of Tags
Input 123456 (or Master Code)
→
10 SSSSS EEEEE
[e.g.] Delete User Address: 00101~00245
Enter program mode
→
10 00101 00245
9
9
Add a Single Tag or Random tags
Input 123456 (or Master Code)
→
19 UUUUU 00001
→
Present the tag(s) to Access Controller
(single tag or random tags one by one)
→
Done
[e.g.] Add 2 random cards to User Addresses No. 100 and No. 101:
Enter program mode
→
19 00100 00001
→
Present the tags one by one
→
Done
Input 123456 (or Master Code)
→
19 UUUUU QQQQQ
→
Present the tag
(only use the tag with the lowest number)
→
OK
Add a batch of Sequential tags
[e.g.] Add 20 pcs sequential tags (62312~62331) to User Address NO.101 ~ NO.120:
Enter program mode
→
19 00101 00120
→
Close Tag into RF Area
(only use the tag NO.62312)
→
OK
Tag Information
(125kHz)
※
For Mifare tags, the separator between Site Code & Card Code is comma "
,
".
SITE CODE
CARD CODE
SITE CODE
CARD CODE
M6
※
In this mode, User Address = Card Code
※
If you want to program system on AR-331 (H-S) directly, please order WG keyboard then install it according to the following pattern.
Add Tags
Input 123456 (or Master Code)
→
11 SSSSS EEEEE
→
OK
[e.g.] Add User Address: 00100~01254
Enter program mode
→
11 00100 01254
→
OK
Delete All Tags
Input 123456 (or Master Code)
→
29 29
Delete Tags
Input 123456 (or Master Code)
→
10 SSSSS (or )EEEEE
→
OK
[e.g.] Delete a tag with card code 62362
Enter program mode
→
10 62362 62362
→
OK
9
Reader
POWER
12VDC
Converter
POWER
12VDC
Connect to Reader for Connect to Networking for P7P7
Remove the Protection plug that at the right bottom.
(
※
Do not lose protection plug or it will affect the protection level.)
WG Keyboard cable will be connected to the pin board.
WG Keyboard connected to the controller from the bottom right of the hole.
When you nish programming system, please put protection plug back to
the controller.
AR-331 (H) Interaction Area
Metal controller's Presenting scope is smaller than others, and EM:331 (HB) / MIFARE:331 (HD) is different. Refer to the above picture.
※
331 (HB) touch card-area for interaction.
※
331 (HD) touch keyboard area for interaction.
