Introduction SY-5EMM
21
modules from 8MB to 256MB;SIMM modules from 4MB to 64MB.
For 66MHz host bus CPUs use 12ns or faster DIMM modules; for
83MHz or faster host bus CPUs use 8ns modules.
Memory configuration Table
SIMM Bank DIMM BanksMEMORY
CONFIGURATION
Bank 1,2 DIMM 1 DIMM 2
RAM Type FPM/EDO/BEDO EDO/SDRAM EDO/SDRAM
Single RAM
Module Size (MB)
4/8/16/32/64
8/16/32/64/128/
256
8/16/32/64/128/
256
Notice: 1.You must install two SIMM modules to complete the SIMM Bank
2. Do not use EDO type of DIMM if you already use SDRAM.
Step 7. IDE Device Installation (HDD, CD-ROM)
This mainboard offers two primary and secondary IDE device
connectors (IDE1, IDE2.) It can support up to four high-speed HDD
or CD-ROM.
Connect one side of the 40-pin flat cable to the IDE device (HDD or
CD-ROM) and plug the other end to the primary (IDE1) or secondary
(IDE2) directionally keyed IDE connector on the mainboard.
This mainboard can support up to four HDDs.
Step 8. Floppy Drive Installation
The system supports 5 possible floppy drive types: 720 KB, 1.2 MB,
1.44 MB, 2.88 MB, and LS-120. In addition, this mainboard supports
a 3-mode (720KB/1.25MB/1.44MB) floppy commonly used in Japan.
Connect one side of the 34-pin flat cable to the floppy drive and plug
the other end to the floppy drive connector on the mainboard.
This mainboard can support up to 2 floppy drives.
