Step 8. Other Connections
1. Wake-On-LAN (WOL)
Attach the 3-pin connector from the LAN card which supports the
Wake-On-LAN (WOL) function to the JP44 header on the
Motherboard. This WOL function lets users wake up the connected
computer through the LAN card.
Please install according to the following pin assignment:
2. Infrared (IR1)
Plug the 5-pin infrared device cable to the IR1 header. This will
enable the infrared transfer function. This Motherboard meets both
the ASKIR and HPSIR specifications.
Please install according to the following pin assignment:
3. Other Display Cards
Insert other types of VGA cards into the PCI or ISA expansion slots
according to card specifications.
1 23 4 5
VCC IRRX GND IRTX
Infrared (IR1) Connector
IR1 Pin Assignment
Wake-On-LAN
JP44 Pin Assignment
GND
1
2
3
5VSB
MP - Wake-up
