3-8 INTEGRATED PERIPHERALS
Caution: Change these settings only if you are already
familiar with the Chipset.
The [INTEGRATED PERIPHERALS] option changes the values of
the chipset registers. These registers control the system options in
the computer.
The following screen shows setup default settings.
ROM PCI/ISA BIOS
INTEGRATED PWEIPHERALS
AWARD SOFTWARD, INC.
IDE HDD Block Mode : Enabled Onboard Serial Port 1 : 3F8/IRQ4
IDE Primary Master PIO : Auto Onboard Serial Port 2 : 2F8/IRQ3
IDE Primary Slave PIO : Auto UART Mode Select : Normal
IDE Primary Master UDMA : Auto
IDE Primary Slave UDMA : Auto
IDE Secondary Master UNMA : Auto Onboard Parallel Port : 378/IRQ7
IDE Secondary Slave UDMA : Auto Parallel Port Mode : SPP
On-Chip Primary PCI IDE : Enabled
On-Chip Secondary PCI IDE : Disabled
USB Keyboard Support : Disabled
Init Display First : PCI Slot
Onboard FDC Controller : Enabled
ESC : Quit
↑ ↓ → ←
: Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift) F2 : Color
F7 : Load Setup Defaults
The following tables describe each field in the INTEGRATED
PERIPHERALS Menu and provide instructions on how to configure
the IDE controls, FDC controls, and the onboard serial and parallel
ports.
