Setup
Note:
The modem link must be established within 45 seconds for the 90217. If this does not
happen, switch the monitor OFF and return to step 1.
5 When the information transfer is complete, the ABP monitor beeps and voice communication is
restored.
• Switch the monitor OFF and disconnect it from the modem.
• If there is a direct connection between the monitor and the base station, switch the monitor
OFF and disconnect it from the ABP data interface unit.
To transfer readings from the monitor to the base station:
1 Contact the base station by telephone (for remote operation only).
2 Ask the base station operator to read the monitor. Give the following information to the operator:
• Patient's name.
• Patient ID number.
• Any other information that the base station operator may request.
3 The base station operator enters the patient information into the computer. (If the monitor is in
a remote location, the operator must turn power to the base station modem ON.)
4 Prepare the monitor to transfer data to the base station.
• Switch the modem ON.
• When instructed by the base station operator, switch the ABP monitor ON (for remote
operation only).
Note:
The modem link must be established within 45 seconds for the 90217. If this does not
happen, switch the monitor OFF and return to step 1.
5 When the information transfer is complete, the ABP monitor beeps and voice communication is
restored.
• Switch the monitor OFF and disconnect it from the modem.
Modem Indicator Lights
When the monitor is switched ON, the modem’s RD (receive data) and SD (send data) lights flash
for several seconds. The OH (on hook) indicator is lit when the monitor starts communicating with
the remote modem. When both modems connect, the CD (carrier detect) is lit. The SD and RD
lights flash as data is being transferred.
After the transmission is complete and the monitor is turned OFF, the HS, TR and MR indicators
will always remain lit at the local modem.
