The Hayes Smartmodem 1200, which attaches to the monitor, must be set up as follows:
2 Connect the serial port cable (P/N 012-0096-xx) between the monitor and the modem.
Note:
If call waiting or call forwarding are options on the telephone used to transfer data,
ensure that both are deactivated or modem communications may be interrupted. In
addition, telephone systems, such as CBX or PBX, can cause interference with the
modem, or the modem can cause interference with the switching system.
To initialize the monitor for a remote connection:
1 Contact the base station by telephone (for remote operation only).
2 Ask the base station operator to initialize the monitor. Give the following information to the
operator:
• Patient's name.
• Patient ID number.
• If the monitor display is to be active or inactive.
• Time of day (12- or 24-hour format).
• If measurements are to be displayed (systolic/diastolic and heart rate).
• Multiple or single cycle times. If using a single cycle for the 24-hour monitoring period,
indicate the cycle interval and whether the tone is ON or OFF. For multiple cycle time,
specify each cycle interval and whether the tone is ON or OFF for each cycle.
• Any other information the base station operator may request.
3 The base station operator enters the patient information in the computer.
4 Prepare the monitor to receive the patient data from the base station.
• Switch the modem ON.
• When instructed by the base station operator, switch the ABP monitor ON.
Switch #
Setting at
Monitor Site
1 down
2up
3 down
4 down
5 down
6up
7up
8 down
9up
10 up
