Ambulatory Blood Pressure Monitor 90217 Service Manual
2-9
Setup
PC Interface Test
Note:
The PC Inferface Test is only applicable for use with a PC System that operates with
the 90219 software.
1 Connect the system as illustrated:
2 Power ON all devices.
3 Start the 90219-03 Base Station software (loaded on hard drive).
4 Type: ABP (or ABPPCI) and press the Enter key on the base station.
Note:
If the file name has been changed from ABP, type DIR and press Return to determine
the new name.
5 Switch the 90217 power switch ON.
6 Press (in this order):
Space Bar
1 (ABP communication)
3 (direct connect - skip this step if a PC Interface data key is attached instead of a
base station data key)
2 (read ABP unit)
7 Press any key (wait).
8 Type 8, press the Enter key, and type Y (yes).
Note:
“8” is the name of a dummy file, which should be setup on the computer already.
9 Press the END key.
10 Verify that the clinical data appears on the computer screen. The last reading on this screen is
the results of the test done earlier in these procedures.
11 Verify that the date and time are correct and that the event code EC18 appears.
12 Press the ESC key.
13 Initialize the 90217 by typing:
1 (initialize ABP)
14 Press the END key and use the up arrow key until PATIENT NAME is selected.
15 Type:
TEST and press the Enter key
1234567890 and press the Enter key
NONE and press the END key
16 Verify that the display reads “***MONITOR INITIALIZED***”.
