Ambulatory Blood Pressure Monitor 90217 Service Manual
4-11
Maintenance
7 Perform a leak rate check on the blood pressure simulator and associated tubing as follows:
a While in the Main Menu, move the cursor to Press and select Leak Test by pressing ENT.
b Connect a squeeze bulb to the hose, which will connect directly to the unit under test.
c Pump up the system pressure to approximately 170 mmHg.
d Wait 10 seconds for the pressure to stabilize.
e Press the START (F1) key on the CuffLink simulator and wait one minute while the leak
rate is measured.
f At the end of the minute, the leak rate will appear on the CuffLink display.
g If the leak rate is greater than 10 mmHg/min, retighten all external hose connections and
repeat the test. If the system continues to fail, isolate each length of tubing to locate and
repair the source of the leak.
h Press the Esc key to return to the Main Menu.
90217 Test Preparation
1 Set up the ABP monitor by connecting it to the CuffLink.
2 Refer to the table below for a list of systolic/diastolic/heart rate settings to be performed on the
90217 monitor:
Pressure Setting Range
Systolic 60 52 to 60
Diastolic 30 26 to 33
Heart Rate 40
Systolic 100 91 to 103
Diastolic 65 60 to 70
Heart Rate 60
Systolic 120 111 to 124
Diastolic 80 74 to 88
Heart Rate 80
Systolic 150 143 to 161
Diastolic 100 92 to 108
Heart Rate 120
Systolic 200 196 to 218
Diastolic 150 142 to 158
Heart Rate 120
Systolic 255 253 to 277
Diastolic 195 185 to 205
Heart Rate 120
