Ambulatory Blood Pressure Monitor 90217 Service Manual
4-13
Maintenance
CuffLink Manual Operation
The following steps outline the manual selection of simulated blood pressures and heart rates.
These may be used to repeat a reading which was out of range or produced no reading.
1 When the CuffLink is warmed up, move the cursor to the SelectBp option of the Main Menu
and ADAMS Adult. Press the ENT key to make a selection.
2 Press the F2 key and verify that the gain is set to 100%. At the same time, verify that the SHIFT
and/or OFFSET are at 0. Press the ENT key.
3 Press the F1 key to move to the Heart Rate menu. Use the arrow keys to move the cursor to
the desired heart rate. Press the ENT key to make a selection.
4 Use the arrow keys to move the cursor to the desired blood pressure and press the ENT key.
5 The CuffLink is ready to simulate the selected heart rate and pressure. Press the START/STOP
button on the monitor to begin.
CuffLink Automatic Operation
Use the following procedure to set or change the automatic sequences stored in the CuffLink:
1 Move the cursor to the Auto option of the Main Menu and select Utility by pressing the ENT
key.
2 Use the arrow keys to move the cursor to the EDIT box. Select sequences to edit and press the
appropriate button (F1, F2, F3, etc.). F1 is assigned to ADULT. In the first screen, answer YES
to the Pop-OFF test and NO for the rest. The second and third screens list the sequence of
blood pressures and heart rates. Use the arrow keys to move around the list and use the F4
and F5 keys to change the settings. Set CYCLES for each blood pressure reading. When
finished making changes, press F3 (STORE) to end the edit session.
3 Use the arrow keys to move the cursor to the NAME box. Select the sequence to be named
and press the appropriate button (F1, F2, F3, etc.). Use the arrow keys to move to each
character and use the UP and DOWN arrow keys to change the character. When complete,
press ENT to end the edit.
