HEIGHT ADJUSTMENT
TO ADJUST BACKBOARD:
1. Grasp handle
and squeeze trigger.
2. Raise or lower to
desired height.
3. Release trigger.
REQUIRED TOOLS
AND MATERIALS:
AND/OR
OPTIONAL TOOLS
AND MATERIALS:
1/2”
9/16”
3/4”
• 2 Capable Adults
• Tape Measure
• Wood Board
(scrap)
• Sawhorse or
Support Table
• Hammer
• Safety Glasses
• Step Ladder - 8ft.
(2.4 m)
• Phillips-Head
Screwdriver
SAND
300 lb.
(136 kg)
• (2 each) Wrenches and/or Socket
Wrenches and Sockets (Deep-
Well Sockets are Recommended).
• Extension is Recommended.
• Large and Small Adjustable
Wrenches
9/16”
1/2”
3/4”
