SPALDING 881042 - Net Installation Procedure

29
NET INSTALLATION
9.
Install net (40) onto rim (39).
OUTSIDE VIEW
B.
D.
C.
A.
39
40
39
40
Install cover (42) over spring return mechanism using screws (43) as shown.
Cover plate (42) will fit
INSIDE back bracket.
NOTE:
8.
RIM COVER ATTACHMENT
43
43
39
39
42
42
56
