SPALDING 881042 - Parts Identification; Parts List Overview

7
PARTS LIST - See Hardware Identifier
Item Qty. Part No. Description
1 1 901772 Top Pole Section
2 1 901771 Middle Pole Section
3 1 901817 Bottom Pole Section
4 2 202800 Ground Sleeve, Half
5 1 202801 Ground Sleeve Cap
6 1 203279 Anti-skid Tape
7 1 600343 Trigger, Elevator
8 1 801477 Cover, Spalding
9 1 903601 Rebar
10 2 204159 Clip, Plastic, Rebar Holder
11 1 600137 Pole Cap, Round
12 1 208762 Bolt, Hex, M4 x .7 x 25mm Long
13
6
203100 Nut, Hex Flange, 5/16-18
14 2 901416 Elevator Arm, Upper
15 2 901532 Elevator Arm, Lower
16 2 204846
Bolt, Carriage, 5/16-18 x 4.5” Long
17 1 206990 Pole Reinforcement Bracket
18 6 206340
19 6 201436
Nylon Lock Nut, Hex, 1/2-13
Spacer 0.530 ID x 0.73 OD x .75 Long
20 1 202739 Bolt, Hex 5/16-18 x 1.75” Long
21 1 702723 Gas Strut Assembly
22 1 108163
23 2 206279
Lift Bracket
Bolt, Hex, 1/2-13 x 6.50” Long
24 1 203099 Nut, Nylock, 5/16-18
25 1 901677 Support Plate, Rim
26 1 Backboard
27 1 900033 Bracket, Slam Jam
28 1 206048 Bolt, Tee, 3/8-16, 3.25” Long
29 2 901527 Tube, Gas Strut, Handle Arms
Item Qty. Part No. Description
30 4 208828 Plug, Tube, Snap In, 1.25”, Black
31 2 208829 Plug, Tube, Snap In, 1”, Black
32 1 200318 Bracket, Reinforcement, Slam Jam
33 1 208760 Spring, Rim
34 1 500065IG Label, Height Adjustment
35 1 600342 Handle, Gas Lift
36 2 901508 Tube, Vertical Elevator, Gas Strut
37 1 203795 Nut, Special, 3/8-16
38 4 208892 Bolt, Hex Flange, 5/16-18 x 1.625” Long
39 1 Rim
40 1 Net
41 1 203470 Washer, Flat, 0.625 I.D. x .1.5 O.D.
42 1 200503 Rim Cover, Black
200504 Rim Cover, Red
43 2 200520 Screw, #8 x 3/4 Long
44 1 20157801 Board Pad, Left Section
45 1 20157901 Board Pad, Right Section
46 1 201580 Board Pad, Center Section
47 1 205355 Drill Bit, 11/64”
48 2 201596 Screw, 1/4 x 1.25”
49 6 206303 Washer, Flat, 1/4”
50 4 202871 Screw, 1/4 x .75”
51 2 208668 Bolt, Hex 3/8-16 x 5.50” Long
52 4 209166
Spacer, 0.51 ID x 0.75 OD x 0.67 Long
53 1 201683 Spacer, 0.53 ID x 1.50 Long
54 4 206244 Bolt, Hex, 1/2-13 x 8” Long
55 1 204007 Nut, Nylock, M4 x 0.7
56 1 20279502 Label, Spalding
57 2 203063 Nut, Ny-lock, 3/8-16
* You may have extra parts with this model.
58 1 220579 Spacer, 0.51 I.D. x 5.0 Long
