SPALDING M7B60E00 - Page 39

Parts List
39
Item Qty Part No. Description Item Qty Part No. Description
1 1 600076 Top Base 27 1 Rim
2 1 901183 Bottom Pole Section 28 1 Net
3 2 901184 Top Pole Section 29 1 600077 Stadium Pad, Bottom
4 2 908459 Strut, Front, 62.75” L, with Holes 30 1 600078 Stadium Pad, Top
5 2 908699 Strut, Rear, 62.75” L 31 1 203124 Ground Stake
6 1 700376 Bottom Base 32 1 574090
Label, Height Adjustment and
Moving
7 2 600074 Wheel, 6” 33 1 204872 Label, Height Indicator
8 1
60007901 Transport Handle, Gray
A1 4 205711 Bolt, Hex-Head, 1/2-13 x 2.25” L
60007902 Transport Handle, Black
9 1 800373 U-Bracket, Pivot A2 7 206340 Nut, Nylock, 1/2-13
10 1 908466 Bracket, Wheel A3 14 203474 Washer, Flat, 1.08” OD
11 1 206948 Bracket, Pivot, Lower A4 4 201651 Bushing, Plastic, 0.50 IDx0.25” L
12 1 206956 Disk, Pivot, Plastic A5 3 207876 Bolt, Hex-Head, 1/2-13 x 8.4” L
13 1 908513 Cross Member A6 4 208251 Bushing, Plastic, 0.50 IDx0.13” L
14 1 20694001 Axle, Rod, 20.5” L A7 2 204620 Spacer, Plastic, Black 1.7” L
15 2 908460 Tube, Hinged B1 4 265523 Bolt, Hex Head, 3/8-16 x 1” L
16 1 700009 Handle, Screw-Jack B2 12 203309 Washer, Flat, 3/8 x 1 OD
17 1 80034403 Screw Jack B3 2 203041 Nut, Hex-Flange, 3/8-16
18 1 60016401 Sleeve, Screw Jack B4 2 203331 Bolt, Hex Head, 3/8-16 x 1.5” L
19 1 600165 Cap, Screw Jack B5 4 203063 Lock-nut, Nylon Insert, 3/8-16
20 1 202528 Pin, Handle B6 1 206340 Lock-nut, Nylon Insert, 1/2-13
21 1 908508 Elevator Tube, Upper B7 4 202602
Lock-washer, 0.375 ID x 0.675
OD
22 1 908509 Elevator Tube, Lower B8 1 206304
Bolt, Hex Head, 1/2-13 x 6-5/16”
L
23 1 Backboard B9 1 208617
Bolt, Hex Head, 5/16-18 x 5.63
x 0.91” L
24 2 266300 Plug Cap B10 2 203218 Washer, Flat, 5/16
25 4 208482
Spacer, Steel 0.50” IDx 0.875”
ODx 0.465” L
B11 1 207610 Nut, Acorn, 5/16-18
26 1 20755201 Pad, Foam E1 1 201518
Bolt, Hex-Head, 5/16-18 x 2.75”
L
