SPALDING M7B60E00 - Elevator Mechanism Assembly

Elevator Assembly
21
Elevator Assembly
Required Parts: Completed Elevator Assembly:
• Kit 4
• 1/2" Socket Wrench or
Wrench
G
INSTALL THE ELEVATOR ASSEMBLY
1. Securely rest the assembly on a sawhorse.
2. Slide the screw-jack sleeve (18) over the screw jack and attach the cap (19) to the top end.
#19
#18
NO PA D
(Hole faces rear of pole (#2))
