Assemble the Upper Elevator
23
Assemble the Upper Elevator
Required Parts: Completed Backboard Assembly:
• Kit 5
• 3/4" Socket Wrench or
Wrench
• Socket Wrench Extension
• Sawhorse
WARNING
TWO PEOPLE ARE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS
INJURY AND/OR PROPERTY DAMAGE.
H
ATTACH THE ELEVATOR TUBE ASSEMBLY
1. Securely rest the assembly on a sawhorse. Identify the elevator tubes (21 and 22).
#22
#21
To Next Page
