Package Contents
6
WHEEL TO BASE ASSEMBLY
#7
#8
#9
#10
#14
#15#11#12
#13
7 Wheel, 6” (x2) 8 Transport Handle, Plastic (x1) 9 U-Bracket, Pivot (x1)
10 Bracket, Wheel (x1) 11 Bracket, Pivot, Lower (x1) 12 Disk, Pivot, Plastic (x1)
13 Cross Member (x1) 14 Axle, Rod, 20.5” Long (x1) 15 Tube, Hinged (x2)
KIT 3 – WHEEL ASSEMBLY – BA00005
200514 hex head bolt 3/8-16 x 3
265563
BOLT, HEX, 3/8-16 X 2-1/2, GR5
Bolt, Carriage, 3/8-16 x 2
203277
203041
NUT, HEX FLANGE, 3/8-16
203299 washer 3/8
#W2
#W6
#W3
#W9
#W4
#W7
#W1
#W10
#W8
#W5
W1 Bolt, Hex Head, 3/8-16x3L (x2) W2 Nut, Hex-Flange, 3/8-16 (x12) W3 Washer, 3/8 Flat (x4)
W4 Bolt, Hex Head, 3/8-16x2.5L (x2) W5 Bolt, Hex Head, 3/8-16x4.5L (x1) W6 Lock-Nut, 3/8-16 (x2)
W7 Bolt, Hex Head, 3/8-16x1L (x1) W8 Bolt, Carriage, 3/8-16 x 2 (x8) W9 Push Caps, Metal, Wheel Assembly (x2)
W10 Spacer, 0.379IDx0.5ODx3.5L (x1)
