Package Contents
8
KIT 5 – BACKBOARD – AR00004
#A1
#A2
#A3
#A7
#A4
#A5
(part scaled for page)
#A6
A1 Bolt, Hex-Head, 1/2-13x2.25L (x4) A2 Nut, Nylock, 1/2-13 (x7) A3 Washer, Flat, 1.08OD (x14)
A4 Bushing, Plastic, 0.50IDx0.25L (x4) A5 Bolt, Hex-Head, 1/2-13x8.4L (x3) A6 Bushing, Plastic, 0.50IDx0.13L (x4)
A7 Spacer, Plastic, Black 1.7 L (x2)
GOAL ASSEMBLY
#27
#28
27 Rim (x1) 28 Net (x1)
KIT 6 – GOAL – 222700
203100
NUT, HEX FLANGE, 5/16-18
#R1
#R2
#R3
R1 Bolt, Hex-Flange, 5/16-18x3L (x4) R2 Washer, 3/8, 1 OD (x4) R3 Nut, Hex-Flange, 5/16-18 (x4)
